BEL POWER SOLUTIONS INC HP2320-9RG

Product Information
Number of Outputs:
2
Isolation Voltage:
2.8kV dc
Standards Met:
CCSAus, CE, EN 50121-3-2, EN 50155, IEC/EN 61000-4-2, IEC/EN 61000-4-3, IEC/EN 61000-4-4, IEC/EN 61000-4-5, IEC/EN 61000-4-6, IEC/EN 61000-4-8
Mounting Type:
Rack Mount
Width:
164.1mm
Maximum Temperature:
+71°C
Series:
HP
Input Voltage Range:
12.5 → 154 V dc
Length:
111mm
Railway Approved:
Yes
Efficiency:
92.5%
Depth:
19.6mm
Output Voltage:
±12V dc
Medical Approved:
No
Minimum Temperature:
-40°C
Input Voltage Nominal:
16.8 → 137.5 V dc
Power Rating:
70W
Output Current:
4A
RoHs Compliant

Technical Documents
BEL POWER SOLUTIONS INC
HP Series Datasheet(Technical Reference)
Checking for live stock

More Information

Bel Power HP Series DC-DC Converter Bel Power Solutions HP series of extremely compact DC-DC converters come equipped with all industry standard input & output filters, protection & signalling features. The HP series offers many handy features such as flexible output power, extremely high efficienc...
Bel Power HP Series DC-DC Converter Bel Power Solutions HP series of extremely compact DC-DC converters come equipped with all industry standard input & output filters, protection & signalling features. The HP series offers many handy features such as flexible output power, extremely high efficiency with very low ripple current & RFI noise levels and many more. Construction of the series ensures longevity of the product, with a protective lacquer covering the PCB. The converters have been designed using transformers with Planar technology. Within the converter, there is an input -fed voltage booster which generates 70 V. If the voltage exceeds this rating, then the booster adapts functionality to act as a diode. The series have been designed for use within rugged environments which makes the HP series suitable for railway applications and have been designed in accordance with European railway standards. Features and Benefits Designed in accordance with European railway standards. Extremely wide input range of 12.5 V dc to 154 V dc. Low inrush current. 10 ms interruption time. Lacquer-covered PCB. Up to 92% efficiency rating. Fully enclosed slim casing. Industry standard protection features such as input over & programmable under voltage lockout. 1 to 4 isolated outputs. Standards EN50155, EN50121-3-2 & IEC/EN 61000-4-2, -3, -4, -5, -6 & -8. Safety approved to adhere to IEC/EN 60950-1 & UL/CSA 60950-1 2nd Edition. Bel Power
