Phoenix Contact 3042764
Product Information
Current Rating:
32A
Mounting Type:
DIN Rail
Voltage Rating:
800 V
Series:
Combi Pluggable Solutions
Material:
Polyamide
Pluggable Terminal Block Type:
Plug
Termination Method:
Spring Cage
Pitch:
6.2mm
HTSUS:
8536.90.4000
RoHS Status:
RoHS Compliant
Termination Style:
Screwless - Spring Cage, Tension Clamp
Housing Material:
Polyamide (PA), Nylon
Operating Temperature:
-
Screw Size:
-
Wire Strip Length:
10mm
Type:
Plug, Female Sockets
Number of Positions:
1
Contact Tail Length:
-
Wire Gauge or Range - mm²:
0.08-6mm²
Plug Wire Entry:
180°
Insulation Height:
1.634" (41.50mm)
Material Flammability Rating:
UL94 V-0
Package:
Bulk
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Current - IEC:
32A
Wire Gauge or Range - AWG:
10-28 AWG
Voltage - UL:
600 V
Torque - Screw:
-
standardLeadTime:
7 Weeks
Contact Mating Finish:
-
Voltage - IEC:
800 V
Ingress Protection:
-
Features:
-
Mounting Type:
Free Hanging (In-Line)
Color:
Blue
Series:
CLIPLINE ST-COMBI SP
Positions Per Level:
1
Header Orientation:
-
Current - UL:
30 A
Pitch:
-
Number of Levels:
1
Contact Material:
-
ECCN:
EAR99
Checking for live stock
FAQs
Yes. You can also search 3042764 on website for other similar products.
We accept all major payment methods for all products including ET13267353. Please check your shopping cart at the time of order.
You can order Phoenix Contact brand products with 3042764 directly through our website or call us at +44 (0) 3303 800 157 or email our support team at sales@enrgtech.co.uk.
Yes. Our products in DIN Rail Terminal Accessories category are shipped in lowest possible time.
You will get a confirmation email regarding your order of Phoenix Contact 3042764. You can also check on our website or by contacting our customer support team for further order details on Phoenix Contact 3042764.
We use our internationally recognized delivery partners UPS/DHL. Collection of ET13267353 can also be arranged for the customer by international shipments through contacting our customer support team. Additionally, you can also search "Phoenix Contact" products on our website by using Enrgtech's Unique Manufacturing Part Number ET13267353.
Yes. We ship 3042764 Internationally to many countries around the world.
This is manufactured by Phoenix Contact. The manufacturer part number is 3042764. The product has a current rating of 32a. The product is available in din rail configuration. Moreover, the product has a nominal 800 v voltage rating. The product combi pluggable solutions, is a highly preferred choice for users. The product is made from highly stable and reliable polyamide. It allows spring cage termination method. Moreover, the product is 6.2mm. It is assigned with possible HTSUS value of 8536.90.4000. The product is rohs compliant. Moreover, it has screwless - spring cage, tension clamp terminal style. The product also features robust polyamide (pa), nylon housing material. The typical length of the wire strip is 10mm. It comes in plug, female sockets configuration. The product carries possible position value of 1. A 0.08-6mm² of wire gauge. It also a 180° plug wire entry. 1.634" (41.50mm) of insulation height. It carries ul94 v-0 of material flammability rating. It is shipped in bulk package . Its typical moisture sensitivity level is 1 (unlimited). An IEC current of 32a. While 10-28 awg is its range or wire gauge. While 600 v is the typical voltage of the product. It has a long 7 weeks standard lead time. The nominal voltage of the product is 800 v. The product is available in free hanging (in-line) configuration. It has a classic blue colour. The product clipline st-combi sp, is a highly preferred choice for users. It has 1 positions each level. The typical current includes 30 a. The product carries 1 levels. The product is designated with the ear99 code number.
