Coil Voltage:
600VAC
Termination Style:
Screw Terminal
Operating Temperature:
-40°C ~ 60°C
Coil Resistance:
-
Switching Voltage:
690VAC - Max
Coil Power:
-
Must Operate Voltage:
510 VAC
Manufacturer:
Schneider Electric
Contact Form:
3PST-NO (3 Form A)
Operate Time:
35 ms
Must Release Voltage:
120 VAC
standardLeadTime:
5 Weeks
Contact Rating (Current):
150 A
Features:
-
Mounting Type:
Chassis Mount
Series:
TeSys
Release Time:
130 ms
Packaging:
Box
Contact Material:
-
Contactor Application:
Resistive Load, Motor Control
Maximum Operating Temperature:
60°C
Pole and Throw Configuration:
3P
Series:
LC1F
Minimum Operating Temperature:
-40°C
Coil Voltage:
600 V
Length:
170mm
Operational Current Ie:
150A
Width:
163.5 mm
Depth:
171mm
Contact Current:
150A
Control Circuit Voltage Uc:
600 V
Normal State Configuration:
3 NO
Standards/Approvals:
UL 94, UL 60947-4-1, UL 60335-2-40:Annex JJ, IEC 60947-5-1, IEC 60947-4-1, IEC 60947-1 Annex Q, IEC 60947, IEC 60695-2-1, IEC 60529, EN 60947-4-1, EN 60947-5-1, EN/ISO 13849-1, IEC 60068-2-30, IEC 60335-1:Clause 30.2, IEC 60335-2-40:Annex JJ, CSA C22.2 No 60947-4-1, CSA C22.2 No 14
Contact Voltage:
600V
Power Rating:
75kW
Product Type:
Contactor
Number of Poles:
3
Terminal Type:
Screw Clamp
