HTSUS:
8536.41.0045
RoHS Status:
ROHS3 Compliant
Coil Voltage:
23 ~ 26VAC/DC
Termination Style:
Screw Terminal
Operating Temperature:
-25°C ~ 60°C
Coil Resistance:
-
Switching Voltage:
1000VAC - Max
Coil Power:
650W
REACH Status:
REACH Unaffected
Must Operate Voltage:
-
Package:
Box
Contact Form:
3PST-NO (3 Form A)
Moisture Sensitivity Level (MSL):
Not Applicable
Operate Time:
95 ms
Must Release Voltage:
-
standardLeadTime:
2 Weeks
Contact Rating (Current):
300 A
Features:
Auxiliary Contacts
Mounting Type:
Chassis Mount, DIN Rail
Series:
SIRIUS
Release Time:
80 ms
ECCN:
EAR99
Base Product Number:
3RT1066
Contact Material:
-
Contactor Application:
Power Contactor
Coil Voltage:
23/26 V
Width:
145 mm
Contact Current:
300A
Control Circuit Voltage Uc:
23 to 26 V
Better World Claim:
Repairable by the End User
Operational Current Ie:
160A
Product Type:
Contactor
Maximum Operating Temperature:
60°C
Terminal Type:
Screw
Length:
210mm
Standards/Approvals:
CCC, CE, EAC, IEC 60529, IEC 60947-1, IEC 60947-4-1, IEC 60947-5-1, ISO 13849-1, UKCA, UL
Number of Auxiliary Contacts:
2
Auxiliary Contact Configuration:
2 NO/2 NC
Mount Type:
Screw Fixing
Better World Product:
Yes
Series:
3RT1
Depth:
202mm
Normal State Configuration:
2 NO/2 NC
Contact Voltage:
1000V
Power Rating:
160kW
Number of Poles:
3
Minimum Operating Temperature:
-25°C
