Phoenix Contact 1605549
Product Information
Current Rating:
30.0A
Mating Type:
N Coded
Pole Format:
5 + PE
IP Rating:
IP67
Series:
SF
Body Orientation:
Straight
Voltage Rating:
630.0 V
Coding:
N
Contact Gender:
Female
Termination Method:
Crimp
Housing Material:
Copper Zinc Alloy, Die Cast Zinc
Plug/Socket:
Socket
Connector Size:
M23
Minimum Operating Temperature:
-40°C
Shell Size:
M23
Mounting Type:
Cable Mount
Number of Contacts:
5 + PE
Maximum Operating Temperature:
+125°C
HTSUS:
8536.69.4020
RoHS Status:
RoHS Compliant
Mounting Feature:
-
Note:
Contacts Not Included
Operating Temperature:
-40°C ~ 125°C
Shell Size, MIL:
-
Type:
For Female Sockets
Number of Positions:
6 (5 + PE)
Shielding:
Shielded
Shell Material:
Gadolinium-Zinc
Includes:
-
Housing Color:
Silver
Material Flammability Rating:
-
Contact Shape:
Circular
Contact Size:
2.0mm
Package:
Bulk
Shell Size - Insert:
M23-6
Connector Type:
Plug Housing
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Fastening Type:
Threaded
standardLeadTime:
8 Weeks
Insert Material:
Polyamide (PA66), Nylon 6/6
Orientation:
N (Normal)
Ingress Protection:
IP67 - Dust Tight, Waterproof
Features:
Backshell, Coupling Nut
Mounting Type:
Free Hanging (In-Line)
Shell Finish:
-
Series:
SF
Contact Type:
Crimp
ECCN:
EAR99
Checking for live stock
FAQs
Yes. You can also search 1605549 on website for other similar products.
We accept all major payment methods for all products including ET10486868. Please check your shopping cart at the time of order.
You can order Phoenix Contact brand products with 1605549 directly through our website or call us at +44 (0) 3303 800 157 or email our support team at sales@enrgtech.co.uk.
Yes. Our products in Circular Connector Housings category are shipped in lowest possible time.
You will get a confirmation email regarding your order of Phoenix Contact 1605549. You can also check on our website or by contacting our customer support team for further order details on Phoenix Contact 1605549.
We use our internationally recognized delivery partners UPS/DHL. Collection of ET10486868 can also be arranged for the customer by international shipments through contacting our customer support team. Additionally, you can also search "Phoenix Contact" products on our website by using Enrgtech's Unique Manufacturing Part Number ET10486868.
Yes. We ship 1605549 Internationally to many countries around the world.
This is manufactured by Phoenix Contact. The manufacturer part number is 1605549. The product has a current rating of 30.0a. It is a type of n coded mating. While the pole has 5 + pe format. It is IP rated with ip67. The product sf, is a highly preferred choice for users. It has straight body orientation. Moreover, the product has a nominal 630.0 v voltage rating. The product is coded with n. This female contact is widely suited for specific applications. It allows crimp termination method. The product also features robust copper zinc alloy, die cast zinc housing material. It comprises a socket. The connector has m23 size. Whereas, the minimum operating temperature of the product is -40°c. The shell has m23 size. The product is available in cable mount configuration. The product contains 5 + pe contacts. It has a maximum operating temperature of +125°c. It is assigned with possible HTSUS value of 8536.69.4020. The product is rohs compliant. Note: contacts not included. The product has -40°c ~ 125°c operating temperature range. It comes in for female sockets configuration. The product carries possible position value of 6 (5 + pe). Furthermore, the product is shielded with shielded. It is made from highly reliable gadolinium-zinc materials. It has an integral silver housing colour. It has a typical circular shape. While it has a 2.0mm of contact size. It is shipped in bulk package . The insert's size is m23-6. plug housing Connector type offer robust functionality. Its typical moisture sensitivity level is 1 (unlimited). Furthermore, threaded is the Fastening Type of the product. It has a long 8 weeks standard lead time. While it is also supplied with highly stable polyamide (pa66), nylon 6/6 insert material. The product has a n (normal) orientation. It is IP rated with ip67 - dust tight, waterproof. The splendid features of the product include backshell, coupling nut. The product is available in free hanging (in-line) configuration. It has typical contact type of crimp. The product is designated with the ear99 code number.
