Dimensions:
20 x 29mm
Lead Length:
40mm
Equivalent Series Resistance:
25.1 mΩ @ 5 → 100 kHz (105°C), 40 mΩ @ 100 kHz (20°C)
Capacitance:
900 µF
Tolerance:
-10 → +30%
Dielectric Material Family:
Aluminium Electrolytic
Construction:
Aluminium Can
Maximum Operating Temperature:
+105°C
Tolerance Plus:
+30%
Lead Diameter:
1mm
Length:
29mm
Leakage Current:
174.1 μA
Package/Case:
Axial, Can
Diameter:
20mm
Ripple Current:
1.06 (A @100 Hz 105°C), 2.2 (A @= 5 kHz 105°C), 3.3 (A @= 5 kHz 100°C), 5.9 (A @= 5 kHz 80°C), 7.2 (A @= 5 kHz 60°C)
Mounting Type:
Through Hole
Series:
PEG130
Tolerance Minus:
-10%
Voltage:
63 V dc
Minimum Operating Temperature:
-40°C
Lifetime:
37000 h @ +105 °C/Ir
Technology:
Electrolytic
CAD Drawing:
3D CAD Model
Ratings:
-
HTSUS:
8532.22.0040
RoHS Status:
ROHS3 Compliant
ESR (Equivalent Series Resistance):
94mOhm @ 100Hz
Polarization:
Polar
Capacitance:
900 µF
Operating Temperature:
-40°C ~ 105°C
Package / Case:
Axial, Can
Tolerance:
-10%, +30%
Voltage - Rated:
63 V
Height - Seated (Max):
-
REACH Status:
REACH Unaffected
Ripple Current @ Low Frequency:
1.06 A @ 100 Hz
edacadModel:
PEG130MH3900QL1 Models
Applications:
General Purpose
Surface Mount Land Size:
-
edacadModelUrl:
/en/models/4918903
Package:
Bulk
Size / Dimension:
0.787" Dia x 1.142" L (20.00mm x 29.00mm)
Moisture Sensitivity Level (MSL):
Not Applicable
Mounting Type:
Through Hole
Series:
PEG130
Lifetime @ Temp.:
37000 Hrs @ 105°C
Lead Spacing:
-
Base Product Number:
PEG130M
ECCN:
EAR99
