Cooper Bussmann HCP0805 Series Type 0805 Shielded Wire-wound SMD Inductor with a Composite Iron Powder Core, 440 nH ±20%

HCP0805-R68-R Cooper Bussmann HCP0805 Series Type 0805 Shielded Wire-wound SMD Inductor with a Composite Iron Powder Core, 440 nH ±20%
Cooper Bussmann

Product Information

Maximum DC Resistance:
4.5mΩ
Inductor Construction:
Wire-Wound
Dimensions:
7.4 x 7.7 x 5mm
Shielded:
Yes
Series:
HCP0805
Length:
7.4mm
Height:
5mm
Maximum DC Current:
25A
Depth:
7.7mm
Core Material:
Composite Iron Powder
Inductance:
440 nH
Maximum Self Resonant Frequency:
2MHz
Maximum Operating Temperature:
+125°C
Tolerance:
±20%
Minimum Operating Temperature:
-40°C
Package/Case:
0805
RoHs Compliant
Checking for live stock

This is HCP0805 Series Type 0805 Shielded Wire-wound SMD Inductor with a Composite Iron Powder Core 440 nH ±20% manufactured by Cooper Bussmann. The manufacturer part number is HCP0805-R68-R. It allows up to 4.5mω maximum DC resistance. The inductor is designed as wire-wound inductor. The given dimensions of the product include 7.4 x 7.7 x 5mm. Shielding Options yes. The product hcp0805, is a highly preferred choice for users. Its accurate length is 7.4mm. In addition, the height is 5mm. While it carries 25a of maximum DC current. The product comes in 7.7mm depth. The core is manufactured from highly durable and reliable composite iron powder materials. The product has a 440 nh inductance value. It provides 2mhz of maximum self-resonant frequency. It has a maximum operating temperature of +125°c. It features ±20% of tolerance value. Whereas, the minimum operating temperature of the product is -40°c. Concerning its package and casing, it is 0805.

pdf icon
HCP0805 Series High Current, High Frequency, Power Inductors Data Sheet(Technical Reference)
pdf icon
Transition to Bussmann Series(Technical Reference)
