Wurth WE-PD2 Series Type 4532 Unshielded Wire-wound SMD Inductor 6.8 μH ±20% 1.54A Idc

744773068 Wurth WE-PD2 Series Type 4532 Unshielded Wire-wound SMD Inductor 6.8 μH ±20% 1.54A Idc
Wurth Elektronik

Product Information

Maximum DC Resistance:
131mΩ
Dimensions:
4.5 x 4 x 3.2mm
Shielded:
No
Series:
WE-PD2
Minimum Operating Temperature:
-40°C
Length:
4.5mm
Height:
3.2mm
Maximum DC Current:
1.54A
Depth:
4mm
Inductance:
6.8 μH
Maximum Self Resonant Frequency:
35MHz
Maximum Operating Temperature:
+125°C
Tolerance:
±20%
Moulded:
Yes
Package/Case:
4532
RoHs Compliant
Checking for live stock

This is Wurth WE-PD2 Series Type 4532 Unshielded Wire-wound SMD Inductor 6.8 μH ±20% 1.54A Idc manufactured by Wurth Elektronik. The manufacturer part number is 744773068. It allows up to 131mω maximum DC resistance. The given dimensions of the product include 4.5 x 4 x 3.2mm. Shielding Options no. The product we-pd2, is a highly preferred choice for users. Whereas, the minimum operating temperature of the product is -40°c. Its accurate length is 4.5mm. In addition, the height is 3.2mm. While it carries 1.54a of maximum DC current. The product comes in 4mm depth. The product has a 6.8 μh inductance value. It provides 35mhz of maximum self-resonant frequency. It has a maximum operating temperature of +125°c. It features ±20% of tolerance value. In addition, it is moulded yes . Concerning its package and casing, it is 4532.

pdf icon
8 Design Tips for Power Inductors from Wurth Elektronik - Application Note(Technical Reference)
pdf icon
Negative Input Resistance of Switching Regulators - Application Note(Technical Reference)
pdf icon
EMC Filter for DC/DC Switching Controller Optimised - Application Note(Technical Reference)
pdf icon
Direct Current Losses at the Output Filter of a Switching Controller - ANP009B Application Note(Technical Reference)
pdf icon
Influence of Control Loop by an Output Filter - ANP006B Application Note(Technical Reference)
pdf icon
Inductor SMD shielded WE-PD2 S 6.8uH Data Sheet(Technical Reference)
