Maximum Peak Pulse Current:
57A
Maximum Reverse Stand-off Voltage:
33V
Dimensions:
4.6 x 2.9 x 2.03mm
Mounting Type:
Surface Mount
Direction Type:
Bi-Directional
Maximum Operating Temperature:
+175 °C
Maximum Reverse Leakage Current:
1µA
Minimum Breakdown Voltage:
36.7V
Peak Pulse Power Dissipation:
600W
Height:
2.03mm
Width:
2.9mm
Length:
4.6mm
Package Type:
DO-214AC (SMA)
Number of Elements per Chip:
1
Minimum Operating Temperature:
-55 °C
Maximum Clamping Voltage:
60.8V
Diode Configuration:
Single
Pin Count:
2
Test Current:
1mA
Voltage - Clamping (Max) @ Ipp:
60.8V
HTSUS:
8541.10.0080
RoHS Status:
ROHS3 Compliant
Operating Temperature:
-55°C ~ 175°C (TJ)
Package / Case:
DO-214AC, SMA
Type:
Zener
REACH Status:
REACH Unaffected
Voltage - Breakdown (Min):
36.7V
edacadModel:
SMA6J33CA-TR Models
Applications:
General Purpose
edacadModelUrl:
/en/models/1578337
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Bidirectional Channels:
1
standardLeadTime:
21 Weeks
Current - Peak Pulse (10/1000µs):
57A (8/20µs)
Voltage - Reverse Standoff (Typ):
33V
Mounting Type:
Surface Mount
Series:
SMA6J, TRANSIL™
Supplier Device Package:
DO-214AC (SMA)
Packaging:
Tape & Reel (TR)
Capacitance @ Frequency:
-
Power Line Protection:
No
Power - Peak Pulse:
600W
Base Product Number:
SMA6J33
ECCN:
EAR99
