Vishay TSM4 YJ Series 11 (Electrical), 13 (Mechanical)-Turn SMD Trimmer Resistor with J-Hook Terminations, 100kΩ ±10%

TSM4YJ104KB25 Vishay TSM4 YJ Series 11 (Electrical), 13 (Mechanical)-Turn SMD Trimmer Resistor with J-Hook Terminations, 100kΩ ±10%
TSM4YJ104KB25
TSM4YJ104KB25
ET16723991
ET16723991
Vishay

Product Information

Shaft Diameter:
1.5 mm
Dimensions:
4.8 x 3.8 x 5.3mm
Mounting Type:
Surface Mount
Series:
TSM4 YJ
Termination Style:
J-Hook
Length:
4.8mm
Temperature Coefficient:
±100ppm/°C
Height:
5.3mm
Number of Turns:
11 (Electrical), 13 (Mechanical)
Depth:
3.8mm
Minimum Operating Temperature:
-55°C
Power Rating:
1/4W
Maximum Resistance:
100 kΩ
Tolerance:
±10%
Maximum Operating Temperature:
+125°C
Orientation:
Side Adjust
RoHs Compliant
Checking for live stock

This is TSM4 YJ Series 11 (Electrical) 13 (Mechanical)-Turn SMD Trimmer Resistor with J-Hook Terminations 100kΩ ±10% manufactured by Vishay. The manufacturer part number is TSM4YJ104KB25. The diameter of the shaft is 1.5 mm. The given dimensions of the product include 4.8 x 3.8 x 5.3mm. The product is available in surface mount configuration. The product tsm4 yj, is a highly preferred choice for users. Moreover, it has j-hook terminal style. Its accurate length is 4.8mm. It exhibits an excellent temperature coefficient of ±100ppm/°c. In addition, the height is 5.3mm. Consist of 11 (electrical), 13 (mechanical) turns. The product comes in 3.8mm depth. Whereas, the minimum operating temperature of the product is -55°c. Feature 1/4w of power rating. The product offers a maximum resistance up to 100 kω. It features ±10% of tolerance value. It has a maximum operating temperature of +125°c. The product has a side adjust orientation.

pdf icon
Datasheet(Technical Reference)
pdf icon
Product Change Notification SFERNICE /Oct 20, 2006/PCN-SF / FL 046- 2005 Rev 0(Technical Reference)
