Assemtech S1016CW, 15 ° Tilt Switch, 1 A, 120V

Enrgtech Part No: ET16848921
|
Manufacturer Part No:
S1016CW
|
Manufacturer: Assemtech

S1016CW Assemtech , 15 ° Tilt Switch, 1 A, 120V

(0)

Product Information

Differential Angle:

15°

Contact Resistance:

3Ω

Maximum AC Voltage:

120V

Mounting Orientation:

Horizontal

Dimensions:

13 (Dia.) x 196.5mm

Maximum Current:

Length:

196.5mm

Minimum Operating Temperature:

-20°C

Maximum Operating Temperature:

+70°C

Terminal Type:

Wire Lead

Checking for live stock

The Assemtech S1016CW is a specialized tilt switch built to detect and respond to changes in orientation. With its 15° tilt sensitivity, 1 A current rating, and 120V capability, this switch is valuable in various applications, offering a simple yet effective means of sensing tilt or motion. Its precise tilt sensitivity, low current rating, and high voltage handling capacity make it a valuable tool in applications where monitoring tilt or activity is essential for safety, control, or automation. Its compact and durable format ensures long-lasting performance in various environmental conditions.

Tilt Sensitivity for Position Detection

A notable feature of the S1016CW is its 15° tilt sensitivity. This means the switch responds when the tilt angle reaches or exceeds 15 degrees from its horizontal position. This precise sensitivity is instrumental in applications where monitoring the orientation or movement of objects is critical.

The Assemtech S1016CW, 15 ° Tilt Switch, 1 A, 120V: Salient Features and Benefits

With a current rating of 1 A and a voltage capacity of 120V, the S1016CW is versatile enough to handle a variety of electrical circuits and loads.
The S1016CW is designed with environmental safety in mind. Unlike some older tilt switches that contain mercury, this switch is mercury-free.
The S1016CW operates on a straightforward principle. It contains a conductive ball that rolls within the switch housing.
When the switch is tilted beyond its 15° threshold, the ball contacts the electrical terminals, completing the circuit.
Measuring only a few centimetres in length, the S1016CW features a compact design that allows for easy integration into various devices and systems.
Its robust construction confirms it can tackle mechanical stress and vibration rigours, making it suitable for indoor and outdoor applications.

Applications in Safety and Automation of the Tilt Switch

The S1016CW tilt switch finds applications in safety and automation systems where detecting orientation changes is crucial, including:

Trigger Alarms
Shut Down Equipment
Initiate corrective actions in response to tilting or movement, enhancing safety and efficiency in various settings.

Tilt Switch S1016CW Data Sheet(Technical Reference)
