Style:
Board to Cable/Wire
HTSUS:
8536.69.4040
RoHS Status:
RoHS Compliant
Housing Material:
Polyamide (PA), Nylon
Operating Temperature:
-
standardLeadTime:
10 Weeks
Number of Positions:
5
edacadModel:
1830155 Models
Housing Color:
White
edacadModelUrl:
/en/models/5131525
Manufacturer:
Phoenix Contact
Voltage Rating:
150V
Wire Gauge:
-
Connector Type:
Header, Male Pins
Contact Finish:
Tin
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Fastening Type:
Detent Lock
Termination:
Solder
Mating Cycles:
-
Current Rating (Amps):
5A
Ingress Protection:
-
Features:
Solder Retention
Mounting Type:
Surface Mount, Bottom Entry, Through Board
Series:
COMBICON PTSM
Packaging:
Tape & Reel (TR)
Pitch:
0.098" (2.50mm)
Contact Material:
-
ECCN:
EAR99
Connector System:
COMBICON PTSM
Number of Contacts:
5
Orientation:
Straight
Housing Material:
Polyamide
Shrouded/Unshrouded:
Shrouded
Series:
PTSM
Contact Material:
Copper Alloy
Contact Gender:
Male
Row Pitch:
2.5mm
Current:
6A
Number of Rows:
1
Standards/Approvals:
cULus Recognised E60425-20110108, DIN EN 61340-5-1, IEC 60068-2-6, IEC 60068-2-70, IEC 60512-1-1, IEC 60512-1-2, IEC 60512-13-5, IEC 60512-15-1, IEC 60512-3-1, IEC 60512-5-1, IEC 60664-1, ISO 6988, UL 94 V0, UL Recognised E118976-20130619, VDE 40048497
Voltage:
160 V
Termination Type:
Solder
Pitch:
2.5mm
Product Type:
PCB Header
Maximum Operating Temperature:
100°C
Minimum Operating Temperature:
-40°C
Mount Type:
Surface
