Automotive Standard:
No
Maximum Power Dissipation Pd:
830W
Product Type:
MOSFET
Maximum Drain Source Voltage Vds:
55V
Channel Mode:
Enhancement
Typical Gate Charge Qg @ Vgs:
595nC
Maximum Drain Source Resistance Rds:
1.3mΩ
Maximum Gate Source Voltage Vgs:
20 V
Forward Voltage Vf:
1.2V
Height:
5.7mm
Width:
23.25 mm
Length:
25.25mm
Package Type:
SMPD
Minimum Operating Temperature:
-55°C
Standards/Approvals:
No
Maximum Continuous Drain Current Id:
550A
Channel Type:
Type N
Maximum Operating Temperature:
175°C
Pin Count:
24
Mount Type:
Surface
FET Feature:
-
HTSUS:
8541.29.0095
RoHS Status:
ROHS3 Compliant
Operating Temperature:
-55°C ~ 175°C (TJ)
Package / Case:
24-PowerSMD, 21 Leads
Rds On (Max) @ Id, Vgs:
1.3mOhm @ 100A, 10V
Gate Charge (Qg) (Max) @ Vgs:
595 nC @ 10 V
Vgs(th) (Max) @ Id:
3.8V @ 250µA
REACH Status:
REACH Unaffected
FET Type:
N-Channel
Drive Voltage (Max Rds On, Min Rds On):
10V
Drain to Source Voltage (Vdss):
55 V
Vgs (Max):
±20V
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Power Dissipation (Max):
830W (Tc)
standardLeadTime:
27 Weeks
Input Capacitance (Ciss) (Max) @ Vds:
40000 pF @ 25 V
Mounting Type:
Surface Mount
Series:
FRFET®, SupreMOS®
Supplier Device Package:
24-SMPD
Packaging:
Tube
Current - Continuous Drain (Id) @ 25°C:
550A (Tc)
Technology:
MOSFET (Metal Oxide)
Base Product Number:
MMIX1T550
ECCN:
EAR99
