Dimensions:
12.5 x 10 x 7.5mm
Electrical Life:
10^5 Operations
Application:
Signal
Terminal Type:
PCB Pin
Coil Resistance:
2504Ω
Life:
10000000 (Mechanical) cycles, 90000 (Electrical) cycles
Standards Met:
CQC 02001001948, RoHS Compliant, UL E133481
Coil Power:
230mW
Maximum Switching Voltage DC:
60V
Maximum Switching Power DC:
30 W
Isolation Coil To Contact:
1.5kV rms
Maximum Operating Temperature:
+70°C
Switching Current:
2A
Maximum Switching Current AC:
2 A
Coil Voltage:
5 V cc
Operating Temperature Range:
-30 → +70°C
Latching:
No
Contact Configuration:
SPDT
Depth:
7.5mm
Relay Switching Classification:
Subminiature Signal Relay
Features:
High Sensitive, 1 Form C Configuration, Wash Tight Type Available
Mounting Type:
PCB Mount
Length:
12.5mm
Height:
10mm
Maximum Switching Current DC:
2 A
Maximum Switching Voltage AC:
125V
Minimum Operating Temperature:
-30°C
Maximum Switching Power AC:
62.5VA
Number of Poles:
1
Contact Material:
AgNi + Au
