Power Switch Type:
High Side
Number of Inputs:
1
Maximum Supply Voltage:
800V
Series:
TN
Switch On Resistance RdsOn:
22mΩ
Automotive Standard:
No
Width:
6.73 mm
Length:
1.78mm
Package Type:
TO-252
Power Switch Topology:
High Side
Minimum Operating Temperature:
-40°C
Standards/Approvals:
ECOPACK2, UL94 V0
Product Type:
Power Switch IC
Maximum Operating Temperature:
150°C
Pin Count:
3
Operating Current:
16A
HTSUS:
8541.30.0080
RoHS Status:
ROHS3 Compliant
Voltage - Off State:
800 V
Voltage - Gate Trigger (Vgt) (Max):
1.3 V
Operating Temperature:
-40°C ~ 150°C (TJ)
Package / Case:
TO-252-3, DPAK (2 Leads + Tab), SC-63
Current - Hold (Ih) (Max):
20 mA
Current - On State (It (RMS)) (Max):
16 A
Package:
Tape & Reel (TR)
Current - Off State (Max):
1 µA
Moisture Sensitivity Level (MSL):
3 (168 Hours)
Current - Gate Trigger (Igt) (Max):
6 mA
standardLeadTime:
15 Weeks
Current - Non Rep. Surge 50, 60Hz (Itsm):
140A, 153A
Voltage - On State (Vtm) (Max):
1.55 V
Mounting Type:
Surface Mount
Current - On State (It (AV)) (Max):
10 A
Series:
ECOPACK2, TN
Supplier Device Package:
DPAK
SCR Type:
Standard Recovery
ECCN:
EAR99
