Arcolectric C1560AAAAA, DPDT, On-On Rocker Switch Panel

Enrgtech Part No: ET13981778
|
Manufacturer Part No:
C1560AAAAA
|
Manufacturer: Arcolectric

C1560AAAAA Arcolectric , DPDT, On-On Rocker Switch Panel

(0)

Product Information

Actuator Shape:

Rectangular

Panel Cut Out Height:

27.2mm

Actuator Colour:

Black

Illuminated:

Mounting Type:

Panel Mount

Contact Current Rating:

16 A

Contact Configuration:

DPDT

Panel Cut Out Width:

22.2mm

AC Voltage Rating:

125 V, 250 V

Panel Cut Out Size:

27.2 x 22.2mm

Terminal Type:

Quick Connect

Switch Operation:

On-On

Checking for live stock

The Arcolectric C1560AAAAA represents a pinnacle of design and functionality in the world of rocker switches. This Double Pole Double Throw (DPDT) switch, with its distinct On-On operation, is engineered for high performance and reliability. It boasts a robust build, ensuring longevity and consistent performance. Its ergonomic rocker design offers a comfortable and intuitive user interface. The switch's compact size allows for easy integration into various panels, maintaining a sleek and unobtrusive appearance. Its wide array of applications and user-friendly format make it a top choice for professionals and hobbyists.

The Arcolectric C1560AAAAA, DPDT, On-On Rocker Switch Panel: Core Characteristics and Advantages

Its DPDT design makes it suitable for various applications, ranging from industrial controls to consumer electronics.
Crafted with high-quality materials, the C1560AAAAA is designed for longevity, even in demanding environments.
The ergonomic rocker design ensures ease of use, making it accessible to several users.
The switch's small footprint allows for easy integration into panels without sacrificing space or aesthetics.

Electrical Specifications

Equipped with a DPDT mechanism, this switch can control two separate circuits, allowing for more complex circuit designs. It operates efficiently in an On-On configuration, providing a seamless transition between two states without an off position. The electrical rating of this model supports various applications, making it a versatile choice for many electrical systems.

Application Flexibility of the Rocker Switch

The Arcolectric C1560AAAAA is incredibly versatile, finding its place in numerous applications. It's widely utilised in:

Industrial Controls: For machinery and control panels where robust and reliable switching is crucial.
Medical Equipment: In devices where precise control and dependability are paramount.
Consumer Electronics: For household appliances and entertainment systems requiring reliable and easy-to-use switches.

Datasheet(Technical Reference)

C1560AA Product Specification Technical Data Sheet(Technical Reference)

ENEC 137203-01(Technical Reference)
