SPNO Reed Relay, 1 A, 24V dc
Product Information
Contact Resistance:
150 mΩ
Dimensions:
31.8 x 9.4 x 8.9mm
Coil Voltage:
24V dc
Coil Resistance:
7845Ω
Life:
100000000Cycles
Standards Met:
RoHS Compliant
Coil Power:
73mW
Maximum Switching Voltage DC:
200V dc
Maximum Switching Power DC:
15 W
Isolation Coil To Contact:
2kV dc
Maximum Operating Temperature:
+70°C
Terminal Type:
Through Hole
Maximum Switching Current AC:
1 A
Operating Temperature Range:
-20 → +70°C
Contact Configuration:
SPST
Depth:
9.4mm
Mounting Type:
PCB Mount
Operating Time Including Bounce:
0.5ms
Length:
31.8mm
Height:
8.9mm
Maximum Switching Current DC:
1 A
Maximum Switching Voltage AC:
200V ac
Minimum Operating Temperature:
-20°C
Contact Material:
Tin Plated Copper Alloy
Checking for live stock
FAQs
Yes. You can also search 291-9732 on website for other similar products.
We accept all major payment methods for all products including ET16737582. Please check your shopping cart at the time of order.
You can order RS Pro brand products with 291-9732 directly through our website or call us at +44 (0) 3303 800 157 or email our support team at sales@enrgtech.co.uk.
Yes. Our products in Reed Relays category are shipped in lowest possible time.
You will get a confirmation email regarding your order of SPNO Reed Relay, 1 A, 24V dc. You can also check on our website or by contacting our customer support team for further order details on SPNO Reed Relay, 1 A, 24V dc.
We use our internationally recognized delivery partners UPS/DHL. Collection of ET16737582 can also be arranged for the customer by international shipments through contacting our customer support team. Additionally, you can also search "RS Pro" products on our website by using Enrgtech's Unique Manufacturing Part Number ET16737582.
Yes. We ship 291-9732 Internationally to many countries around the world.
This is SPNO Reed Relay 1 A 24V dc manufactured by RS Pro. The manufacturer part number is 291-9732. It features a 150 mω contact resistance. The given dimensions of the product include 31.8 x 9.4 x 8.9mm. The coil voltage of the product is 24v dc. It holds up to 7845ω coil resistance. It is capable of doing 100000000cycles in a lifetime . The product complies with all safety standards, such as rohs compliant. Robust coil power of 73mw. While it carries 200v dc of maximum DC switching voltage. It bears a maximum 15 w of DC switching power. The product has 2kv dc isolation coil to contact. It has a maximum operating temperature of +70°c. The terminal is a through hole type. It has a maximum 1 a switching current AC . The product has -20 → +70°c of operating temperature range. The contact is equipped with spst configuration. The product comes in 9.4mm depth. The product is available in pcb mount configuration. Moreover, the product offers a 0.5ms operating time including bounce . Its accurate length is 31.8mm. In addition, the height is 8.9mm. It has a minimum 1 a DC switching current . It has a maximum AC switching voltage of 200v ac. Whereas, the minimum operating temperature of the product is -20°c. The product is made from sturdy tin plated copper alloy materials.
