EPCOS Surface Mount Pulse Transformer 1 : 1 :8.42 Turns Ratio, 3mH Prim. Inductance, 23Ω Prim. Resistance

Enrgtech Part No: ET28424530
|
Manufacturer Part No:
B78416X0001
|
Manufacturer: EPCOS

B78416X0001 EPCOS Surface Mount Pulse Transformer 1 : 1 :8.42 Turns Ratio, 3mH Prim. Inductance, 23Ω Prim. Resistance

Product Information

Primary DC Resistance:

23Ω

Isolation Voltage:

200Vrms

Minimum Operating Temperature:

-40°C

Series:

EP6

Length:

7.6mm

Maximum Operating Frequency:

300kHz

Width:

8.8 mm

Depth:

7.10mm

Standards/Approvals:

RoHS, AEC-Q200

Turns Ratio:

1 : 1 :8.42

Primary Inductance:

3mH

Minimum Operating Frequency:

50kHz

Checking for live stock

This is Surface Mount Pulse Transformer 1 : 1 :8.42 Turns Ratio 3mH Prim. Inductance 23Ω Prim. Resistance manufactured by EPCOS. The manufacturer part number is B78416X0001. Additionally, it has 23ω primary DC resistance . It has 200vrms isolation voltage. Whereas, the minimum operating temperature of the product is -40°c. The product ep6, is a highly preferred choice for users. Its accurate length is 7.6mm. It carries 300khz of maximum operating frequency. Furthermore, the product is 8.8 mm wide. The product comes in 7.10mm depth. It has 1 : 1 :8.42 turns ratio . Additionally, it has 3mh primary inductance . It has a minimum 50khz operating frequency . telecom transformer is a versatile product designed to provide user-defined applications. It has a maximum operating temperature of 125°c. It has a surface type mount .
