MikroElektronika MIKROE-3787

MIKROE-3787 MikroElektronika
MIKROE-3787
MikroElektronika

Product Information

The MIKROE-3787, MikroElektronika, is a high voltage 2 channel H-Bridge 4 click board that drives DC motors and inductive loads in a range of industrial settings. It features various protection features, is easy to use, and is versatile.



Featured Device:
Mikroe-3887
Kit Classification:
Development Kit
Kit Name:
H-Bridge 4 Click
Function:
Motor Controller/Driver
Base Part Number:
MIKROE
Detailed Description:
AP1010AEN Motor Controller/Driver Power Management mikroBUS™ Click™ Platform Evaluation Expansion Board
Utilized IC / Part:
AP1010AEN
Manufacturer Standard Lead Time:
4 Weeks
Packaging:
Bulk
Platform:
mikroBUS™ Click™
Customer Reference:
Type:
Power Management
Contents:
Board(s)
Manufacturer:
MikroElektronika
RoHs Compliant
Checking for live stock

The MIKROE-3787 is a two-channel H-Bridge 4 Click Board developed by MikroElektronika. It is designed to provide an efficient, reliable solution for driving DC motors or other inductive loads in various applications. With a maximum voltage rating of 18V, this Click Board offers versatility and ease of use.

Key Features of MIKROE-3787, MikroElektronika, 2ch, H-Bridge 4 Click Board, 18V:

The MIKROE-3787 H-Bridge 4 Click Board comes equipped with several noteworthy features:

  • Dual-channel H-Bridge: This Click Board features two independent H-Bridges, simultaneously controlling two separate loads. Each H-Bridge provides bidirectional control, allowing forward, reverse, and braking operations.
  • High Voltage Support: With a maximum voltage rating of 18V, this Click Board can drive motors and other inductive loads requiring higher voltage levels. It offers flexibility for a wide range of applications.
  • Current Limiting: The Click Board incorporates current limiting functionality to prevent damage to the H-Bridge and connected loads. This feature ensures the safe operation of motors by protecting against excessive current draw.
  • PWM Support: The MIKROE-3787 supports Pulse Width Modulation (PWM) for precise speed and direction control. The PWM input allows for smooth and accurate speed adjustments, making it suitable for applications that require precise motor control.
  • Overtemperature Protection: The board is equipped with overtemperature protection to safeguard against excessive heat. This feature prevents the H-Bridge from overheating during extended operation, enhancing the overall reliability and lifespan of the system.
  • Diagnostic and Fault Reporting: The MIKROE-3787 includes diagnostic and fault reporting capabilities, providing valuable feedback on the status of the H-Bridge and load conditions. This feature aids in troubleshooting and ensures efficient system monitoring.

Applications Industries of MIKROE-3787, MikroElektronika, 2-ch, H-Bridge 4 Click Board, 18V:

  • The MIKROE-3787 H-Bridge 4 Click Board finds applications in various domains, including robotics, automation, automotive systems, industrial control, etc.
  • It can be used to control DC motors in robotic platforms, actuate valves and pumps, drive conveyor belts, and control other inductive loads in diverse scenarios.
