EPCOS Power Factor Correction Capacitor (PFC) 3 x 48.1μF 12.5kVAR 15kVAR

B25675A5122J525 EPCOS Power Factor Correction Capacitor (PFC) 3 x 48.1μF 12.5kVAR 15kVAR
B25675A5122J525 EPCOS Power Factor Correction Capacitor (PFC) 3 x 48.1μF 12.5kVAR 15kVAR
EPCOS

Product Information

Tolerance Plus:
+5%
Mounting Type:
Stud Mount
Weight:
1.3kg
Capacitance:
3 x 48.1µF
Series:
MKK
Tolerance Minus:
-5%
Height:
200mm
Width:
85mm
kvar 50Hz:
12.5kvar
kvar 60Hz:
15kvar
Voltage:
525V ac
Minimum Operating Temperature:
-40°C
Number of Phases:
3
Maximum Operating Temperature:
+60°C
Dielectric Material:
Polypropylene
Terminal Type:
Screw
RoHs Compliant
Checking for live stock

The EPCOS B25675A5122J525 is a high-performance 3-phase Power Factor Correction (PFC) capacitor designed to optimise electrical efficiency in industrial power networks. Part of the PhaseCap Energy series, this 12.5kvar (at 50Hz) component utilises MKK metallised polypropylene technology to reduce reactive power and minimise energy costs. Housed in a compact cylindrical aluminium casing with a secure stud mount, it features a self-healing dielectric and an overpressure disconnector for maximum safety. It is an environmentally friendly solution, impregnated with a non-PCB, semi-dry, biodegradable, soft resin.

Why Buy the Product?

Improving your system's power factor with this EPCOS B25675A5122J525 reliable capacitor reduces electricity costs and extends the lifespan of electrical equipment.

  • Features advanced self-healing technology and an overpressure disconnector to ensure long-term operational safety.
  • Optimises energy usage by effectively eliminating reactive power and harmonics from industrial power lines.
  • High inrush current withstand capability.
  • Long service life of up to 200,000 hours.
  • Compact design for high panel packing density.

Special Features & Typical Environments

Functional Highlights

  • MKK Technology: Concentric windings provide superior heat dissipation and capacitance stability.
  • Environmental Safety: Uses biodegradable resin instead of toxic oils, making it safe for modern green standards.
  • Robust Terminals: Equipped with secure screw terminals designed to handle high current loads without overheating.
  • Mounting Flexibility: Features a threaded M12 stud at the base for quick, vertical or horizontal installation.

Typical Applications

  • Industrial Plants: Used in automatic PFC systems to compensate for inductive loads from large motors.
  • Commercial Buildings: Improving power quality in HVAC systems and large-scale lighting installations.
  • Renewable Energy: Integrating into power distribution units to stabilise voltage in wind or solar power grids.
