Power Switch Type:
High Side
Number of Inputs:
1
Width:
6 mm
Height:
3.6mm
Automotive Standard:
No
Minimum Supply Voltage:
9.2V
Package Type:
PowerSO-36
Product Type:
Power Switch IC
Maximum Operating Temperature:
125°C
Operating Current:
2.3A
Number of Outputs:
8
Length:
16mm
Standards/Approvals:
IEC 61000- 4-4, IEC 61000-4-2, IEC 61000-4-5 and IEC 61000-4-8, UL1577 and UL508 Certified
Power Switch Topology:
High Side
Pin Count:
16
Mount Type:
Surface
Switch On Resistance RdsOn:
0.26Ω
Series:
ISO808A
Maximum Supply Voltage:
45V
Minimum Operating Temperature:
-40°C
Interface Type:
SPI
Voltage - Supply (Vcc/Vdd):
9.2V ~ 36V
HTSUS:
8542.39.0001
RoHS Status:
ROHS3 Compliant
Supplier Device Package:
PowerSO-36, Bottom Pad
Operating Temperature:
-40°C ~ 125°C (TJ)
Current - Output (Max):
2.3A
Input Type:
Non-Inverting
Package / Case:
36-PowerBSSOP (0.433", 11.00mm Width)
Ratio - Input:Output:
1:8
REACH Status:
REACH Unaffected
Output Type:
N-Channel
Interface:
On/Off, SPI
Moisture Sensitivity Level (MSL):
3 (168 Hours)
standardLeadTime:
25 Weeks
Features:
Auto Restart, Power Good, Status Flag
Mounting Type:
Surface Mount
Series:
-
Voltage - Load:
9.2V ~ 36V
Fault Protection:
Current Limiting (Fixed), Over Load, Over Temperature, Over Voltage, Reverse Current, UVLO
Packaging:
Tape & Reel (TR)
Rds On (Typ):
125mOhm
Output Configuration:
High Side
ECCN:
EAR99
Number of Outputs:
8
Switch Type:
Relay, Solenoid Driver
