Image is for illustrative purposes only.
Please refer to product description.

Manufacturer :	JST
Manufacturer Part No :	BM04B-ZESS-TBT (LF)(SN)
Enrgtech Part No :	ET10002646
Product Range :	PolySwitch RXEF Series

JST ZE BM04B, 1.5mm Pitch, 4 Way, 1 Row, Straight PCB Header, Surface Mount

ZE Series 1.5mm Headers The ZE Series of 1.5mm pitch SMT Headers have reinforcing plates and forked posts for secure PCB mounting and connection. Suction caps for automatic handling are fitted on these ZE Series of 1.5mm pitch SMT Headers. For mating ZE 1.5mm Receptacle Housings see stock number 820-1359 typical. 1.5mm Wire to Board - JST ZE Connectors The JST ZE Series of 1.5mm Wire to Board Connectors feature secure locking housing and contact structures.

Product Information

Shrouded/Unshrouded	:	Shrouded
Current Rating	:	2.0A
Mounting Type	:	Surface Mount
Series	:	ZE
Body Orientation	:	Straight
Termination Method	:	Solder
Connector System	:	Wire to Board
Number of Rows	:	1
Contact Plating	:	Tin
Pitch	:	1.5mm
Number of Contacts	:	4
rohs	:	RoHS Certificate of Compliance
Contact Material	:	Copper Alloy

Technical Documents

ZE Series Wire to Board 1.5mm pitch Connector - Catalogue Pages (Technical Reference)

Availability:

0
in stock
Check now

Rate:

800
+
£ 0.432

Qty:
