Housing Material:
Polyamide
Number of Contacts:
8
Orientation:
Straight
Series:
DFK
Colour:
Green
Current:
32A
Width:
86.46 mm
Length:
48.93mm
Number of Rows:
1
Standards/Approvals:
IEC 61984, EN 60695-2-13, EN 60695-10-2, IEC 60512-1-1:2002-02, IEC 60512-5-1:2002-02, IEC 60512-3-1:2002-02, UL 94 V0, IEC 60512-13-5:2006-02, IEC 60112, cULus Recognised Approval ID: E60425-19920722, EN 60695-2-12, IEC 60068-2-70:1995-12, ISO 6988:1985-02, IEC 60664-1:2007-04, IEC 60512-1-2:2002-02, IEC 60-1:1-11
Voltage:
1000 V
Termination Type:
Screw
Pitch:
7.62mm
Product Type:
Pluggable Terminal Block Headers & Socket
Mount Type:
Screw
Panel Mount Type:
2 Piece, Snap Lock - Front Flange
HTSUS:
8536.69.8000
RoHS Status:
ROHS3 Compliant
Width:
3.404" (86.46mm)
Panel Thickness:
0.039 ~ 0.118" (1.0 ~ 3.0mm)
REACH Status:
REACH Unaffected
Manufacturer:
Phoenix Contact
Wire Gauge:
8-24 AWG
Front Panel Wire Connection:
Header, Male Pins
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Voltage - UL:
600 V
standardLeadTime:
7 Weeks
Number of Levels:
1
Features:
-
Color:
Green
Series:
COMBICON DFK-PC
Positions Per Level:
8
Packaging:
Bulk
Current - UL:
41 A
Pitch:
0.300" (7.62mm)
Rear Panel Wire Connection:
Bolt/Screw Clamp - Wire Entry Parallel to Panel
ECCN:
EAR99
