Housing Material:
Polyamide
Number of Contacts:
8
Orientation:
0°
Wire Connection Method:
T Lox Knee Lever Connection Cable Lug Connection
Minimum Wire Size mm²:
10mm²
Series:
TW 50/4-CL
Colour:
Grey
Minimum Wire Size AWG:
8 AWG
Maximum Wire Size mm²:
50mm²
Current:
15A
Width:
98 mm
Length:
46mm
Number of Rows:
1
Standards/Approvals:
EN 60695-2-13, cULus Recognised, EN 60695-10-2, EN 60695-2-12, IEC 60068-2-82/JEDEC JESD 201, IEC 60947-1:2007-06 + A1:2010-12, IEC 60947-7-1:2009-04, UL 94 V0, VDE approval, WEEE/RoHS
Voltage:
1000 V
Pitch:
20mm
Maximum Wire Size AWG:
1/0 AWG
Product Type:
PCB Terminal Block
Mount Type:
Quick Connect, Wall
Panel Mount Type:
2 Piece
HTSUS:
8536.69.8000
RoHS Status:
RoHS Compliant
Width:
-
Panel Thickness:
0.039 ~ 0.197" (1.0 ~ 5.0mm)
Manufacturer:
Phoenix Contact
Wire Gauge:
1/0-8 AWG
Front Panel Wire Connection:
Push In Clamp - Wire Entry 90° to Panel
Moisture Sensitivity Level (MSL):
1 (Unlimited)
standardLeadTime:
8 Weeks
Number of Levels:
1
Features:
-
Color:
Gray
Series:
TW 50
Positions Per Level:
4
Packaging:
Bulk
Pitch:
-
Rear Panel Wire Connection:
Bolt/Screw Clamp - Wire Entry 90° to Panel
ECCN:
EAR99
