Hazardous Area Certification:
EU
Jacket Colour:
Grey
Outside Diameter:
0.178 in
Conductor Material:
Tin Copper Wire
Series:
Alpha Essentials Communication & Control
Minimum Operating Temperature:
-20°C
Fire Behaviour:
VW-1
Core Strands:
22
Armoured:
No
Screened/Unscreened:
Screened
Conductor Type:
Stranded
American Wire Gauge:
22
Voltage:
150 Vrms
Jacket Material:
Polyvinyl Chloride
Number of Cores:
2
Cable CSA:
0.46 mm²
Product Type:
Control Cable
Maximum Operating Temperature:
80°C
Cable Length:
1000ft
Standards/Approvals:
CE: EU Low Voltage Directive 2014/35/EU, California Proposition 65, CE: EU Directive 2011/65/EU(RoHS2), EU Directive 2015/863/EU (RoHS3), REACH Regulation (EC 1907/2006), UL AWM/STYLE 2576 80°C / 150 VRMS CM 75°C, CSA International CMG 60°C FT4
Ratings:
-
HTSUS:
8544.49.3080
RoHS Status:
ROHS3 Compliant
Conductor Strand:
7/30
Operating Temperature:
-20°C ~ 80°C
Usage:
Communication, Control
Number of Conductors:
2 (1 Pair Twisted)
REACH Status:
REACH Unaffected
Jacket (Insulation) Material:
Poly-Vinyl Chloride (PVC)
Wire Gauge:
22 AWG
Shield Type:
Foil
Jacket (Insulation) Thickness:
0.0320" (0.813mm)
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Length:
1000.0' (304.8m)
Conductor Insulation:
Poly-Vinyl Chloride (PVC)
standardLeadTime:
3 Weeks
Shield Coverage:
100%
Features:
Drain Wire
Jacket (Insulation) Diameter:
0.168" (4.27mm)
Conductor Material:
Copper, Tinned
Series:
-
Cable Type:
Multi-Conductor
Packaging:
Spool
Voltage:
150 V
Shield Material:
Aluminum
ECCN:
EAR99
Base Product Number:
2211C
Jacket Color:
Slate
