Hazardous Area Certification:
No
Jacket Colour:
Grey
Outside Diameter:
0.33 in
Conductor Material:
Tin Copper Wire
Series:
8670
Minimum Operating Temperature:
-10°C
Core Strands:
4
Armoured:
No
Screened/Unscreened:
Screened
American Wire Gauge:
22AWG
Standards/Approvals:
UL, CE: EU Directive 2011/65/EU(RoHS2), CSA International, EU Directive 2015/863/EU (RoHS3), REACH Regulation (EC 1907/2006)
Voltage:
300 Vrms
Jacket Material:
Polyvinyl Chloride
Number of Cores:
4
Cable CSA:
0.34 mm²
Product Type:
Cable
Maximum Operating Temperature:
105°C
Cable Length:
1000ft
Ratings:
ISO 10993, UL Style 2661
HTSUS:
8544.49.3080
RoHS Status:
ROHS3 Compliant
Conductor Strand:
19/34
Operating Temperature:
-
Usage:
-
Number of Conductors:
8 (4 Pair Twisted)
REACH Status:
REACH Unaffected
Jacket (Insulation) Material:
Poly-Vinyl Chloride (PVC)
Wire Gauge:
22 AWG
Shield Type:
Foil, Braid
Jacket (Insulation) Thickness:
0.0400" (1.016mm)
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Length:
1000.0' (304.8m)
Conductor Insulation:
Poly-Vinyl Chloride (PVC)
standardLeadTime:
4 Weeks
Shield Coverage:
100%, 85%
Features:
Biological Compatibility, Drain Wire
Jacket (Insulation) Diameter:
0.324" (8.23mm)
Conductor Material:
Copper, Tinned
Series:
Xtra-Guard® Flex
Cable Type:
Multi-Pair
Packaging:
Spool
Voltage:
300 V
Shield Material:
Aluminum; Copper, Tinned
ECCN:
EAR99
Base Product Number:
86704CY
Jacket Color:
Slate
