Phoenix Contact 1501838
Product Information
American Wire Gauge:
22 AWG
Maximum Operating Temperature:
+80°C
Standards Met:
EAC
Conductor Resistance:
58 O/km
Cable Shape:
Twisted Pair
Conductor Material:
Copper
Series:
SAC-4P-100.0-PVC/0.34
Voltage Rating:
300 V
Fire Behaviour:
Flame Retardant
Oil Resistant:
Yes
Sheath Colour:
Black
Length:
100m
Insulation Material:
PVC
Minimum Operating Temperature:
-40°C
Number of Cores:
4
Cross Sectional Area:
0.34 mm²
Outer Diameter:
5.2mm
Minimum Bend Radius:
5 x D (Fixed), 10 x D (Flexible)
Sheath Material:
PVC
Ratings:
-
HTSUS:
8544.49.3080
RoHS Status:
RoHS Compliant
Jacket (Insulation) Material:
Poly-Vinyl Chloride (PVC)
Operating Temperature:
-25°C ~ 80°C
Usage:
-
Number of Conductors:
4
Conductor Strand:
-
Package:
Bulk
Wire Gauge:
22 AWG
Shield Type:
-
Jacket (Insulation) Thickness:
0.0299" (0.759mm)
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Length:
328.1' (100.0m)
Conductor Insulation:
Poly-Vinyl Chloride (PVC)
standardLeadTime:
8 Weeks
Shield Coverage:
-
Features:
-
Jacket (Insulation) Diameter:
0.205" (5.21mm)
Conductor Material:
Copper, Bare
Series:
-
Cable Type:
Multi-Conductor
Voltage:
300 V
Shield Material:
-
ECCN:
EAR99
Jacket Color:
Black
Checking for live stock
FAQs
Yes. You can also search 1501838 on website for other similar products.
We accept all major payment methods for all products including ET10297984. Please check your shopping cart at the time of order.
You can order Phoenix Contact brand products with 1501838 directly through our website or call us at +44 (0) 3303 800 157 or email our support team at sales@enrgtech.co.uk.
Yes. Our products in Multiple Conductor Cables category are shipped in lowest possible time.
You will get a confirmation email regarding your order of Phoenix Contact 1501838. You can also check on our website or by contacting our customer support team for further order details on Phoenix Contact 1501838.
We use our internationally recognized delivery partners UPS/DHL. Collection of ET10297984 can also be arranged for the customer by international shipments through contacting our customer support team. Additionally, you can also search "Phoenix Contact" products on our website by using Enrgtech's Unique Manufacturing Part Number ET10297984.
Yes. We ship 1501838 Internationally to many countries around the world.
This is manufactured by Phoenix Contact. The manufacturer part number is 1501838. Features 22 awg - American Wire Gauge. It has a maximum operating temperature of +80°c. The product complies with all safety standards, such as eac. The conductor has 58 o/km resistance. Moreover, this cable has a twisted pair shape. The conductor is made from copper material. The product sac-4p-100.0-pvc/0.34, is a highly preferred choice for users. Moreover, the product has a nominal 300 v voltage rating. The product has a flame retardant fire behaviour. Additionally, it is oil resistant yes . The sheath has an adorable black colour. Its accurate length is 100m. It has a robust pvc insulation material. Whereas, the minimum operating temperature of the product is -40°c. The product consists of 4 cores. The product has 0.34 mm² cross section area. Its outer diameter is 5.2mm. It bears 5 x d (fixed), 10 x d (flexible) of minimum bend radius. The sheath is constructed from durable and adorable pvc material. It is assigned with possible HTSUS value of 8544.49.3080. The product is rohs compliant. Its jacket is made from highly insulated poly-vinyl chloride (pvc) materials. The product has -25°c ~ 80°c operating temperature range. It features 4 conductors. It is shipped in bulk package . Moreover, the product has a wire gauge of 22 awg. Furthermore, the insulated jacket is a 0.0299" (0.759mm) thick. Its typical moisture sensitivity level is 1 (unlimited). Its accurate length is 328.1' (100.0m). The conductor offers excellent insulation due to poly-vinyl chloride (pvc) materials. It has a long 8 weeks standard lead time. The diameter of the jacket is 0.205" (5.21mm). The conductor is made from copper, bare material. It is a typical multi-conductor cable. It carries a 300 v of voltage. The product is designated with the ear99 code number. It comes in nice black colour.
