Ratings:
ISO 10993
HTSUS:
8544.49.3080
RoHS Status:
ROHS3 Compliant
Jacket (Insulation) Material:
Poly-Vinyl Chloride (PVC)
Conductor Strand:
7/30
Operating Temperature:
-35°C ~ 105°C
Usage:
Communication, Control
Number of Conductors:
38 (19 Pair Twisted)
REACH Status:
REACH Unaffected
Package:
Spool
Wire Gauge:
22 AWG
Shield Type:
Foil, Braid
Jacket (Insulation) Thickness:
0.0630" (1.600mm)
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Length:
500.0' (152.4m)
Conductor Insulation:
Poly-Vinyl Chloride (PVC)
standardLeadTime:
12 Weeks
Shield Coverage:
100%, 70%
Features:
Biological Compatibility, Drain Wire, Rip Cord
Jacket (Insulation) Diameter:
0.569" (14.45mm)
Conductor Material:
Copper, Tinned
Series:
Xtra-Guard® 1
Cable Type:
Multi-Pair
Voltage:
300 V
Shield Material:
Suprashield®; Copper, Tinned
ECCN:
EAR99
Base Product Number:
5344C
Jacket Color:
Slate
Hazardous Area Certification:
No
Jacket Colour:
Grey
Minimum Operating Temperature:
-35°C
Conductor Material:
Tin Copper Wire
Series:
5344
Fire Behaviour:
EN 60332-2, EN 60332-1
Screened/Unscreened:
Screened
American Wire Gauge:
22AWG
Standards/Approvals:
REACH, IEC, EU Directive 2015/863/EU, CE: EU Low Voltage Directive 2014/35/EU, CE: EU Directive 2011/65/EU(RoHS2), RoHS
Voltage:
300 Vrms
Jacket Material:
Polyvinyl Chloride
Cable CSA:
0.34 mm²
Product Type:
Multicore Cable
Maximum Operating Temperature:
105°C
Cable Length:
500ft
