Hazardous Area Certification:
No
Jacket Colour:
Grey
Outside Diameter:
0.231 in
Conductor Material:
Tin Copper Wire
Series:
8640
Minimum Operating Temperature:
-10°C
Core Strands:
2
Armoured:
No
Screened/Unscreened:
Screened
American Wire Gauge:
28AWG
Standards/Approvals:
UL, REACH Regulation (EC 1907/2006), EU Directive 2015/863/EU (RoHS3), CSA International, CE: EU Directive 2011/65/EU(RoHS2)
Voltage:
300 Vrms
Jacket Material:
Polyvinyl Chloride
Number of Cores:
2
Cable CSA:
0.08 mm²
Product Type:
Cable
Maximum Operating Temperature:
105°C
Cable Length:
1000ft
Ratings:
ISO 10993, UL Style 2661
HTSUS:
8544.49.3080
RoHS Status:
ROHS3 Compliant
Conductor Strand:
7/36
Operating Temperature:
-
Usage:
-
Number of Conductors:
4
REACH Status:
REACH Unaffected
Jacket (Insulation) Material:
Poly-Vinyl Chloride (PVC)
Wire Gauge:
28 AWG
Shield Type:
Foil, Braid
Jacket (Insulation) Thickness:
0.0450" (1.143mm)
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Length:
1000.0' (304.8m)
Conductor Insulation:
Poly-Vinyl Chloride (PVC)
standardLeadTime:
6 Weeks
Shield Coverage:
100%, 85%
Features:
Biological Compatibility, Drain Wire
Jacket (Insulation) Diameter:
0.231" (5.87mm)
Conductor Material:
Copper, Tinned
Series:
Xtra-Guard® Flex
Cable Type:
Multi-Conductor
Packaging:
Spool
Voltage:
300 V
Shield Material:
Aluminum; Copper, Tinned
ECCN:
EAR99
Base Product Number:
86402CY
Jacket Color:
Slate
