Category:
Power MOSFET
Dimensions:
3 x 1.8 x 0.95mm
Maximum Continuous Drain Current:
3 A
Transistor Material:
Si
Width:
1.8mm
Transistor Configuration:
Single
Maximum Drain Source Voltage:
60 V
Maximum Gate Threshold Voltage:
2.5V
Package Type:
SOT-346T (SC-96)
Number of Elements per Chip:
1
Maximum Operating Temperature:
+150 °C
Typical Gate Charge @ Vgs:
9 nC @ 10 V
Channel Type:
N
Typical Input Capacitance @ Vds:
380 pF @ 10 V
Length:
3mm
Pin Count:
3
Typical Turn-Off Delay Time:
30 ns
Mounting Type:
Through Hole
Channel Mode:
Enhancement
Maximum Power Dissipation:
1 W
Maximum Gate Source Voltage:
-20 V, +20 V
Height:
0.95mm
Typical Turn-On Delay Time:
8 ns
Maximum Drain Source Resistance:
154 mΩ
