Deutsch HDP20 Series, 47 Pole Bulkhead Mount Connector Plug, with Male Contacts, IP67

Enrgtech Part No: ET14071868
|
Manufacturer Part No:
HDP26-24-47PE-L015
|
Manufacturer: Deutsch

HDP26-24-47PE-L015 Deutsch HDP20 Series, 47 Pole Bulkhead Mount Connector Plug, with Male Contacts, IP67

Product Information

Number of Contacts:

Current Rating:

13.0 A, 7.5A

Mating Type:

Bayonet

Mounting Type:

Bulkhead Mount

IP Rating:

IP67

Series:

HDP20

Body Orientation:

Straight

Termination Method:

Crimp

Contact Gender:

Male

Housing Material:

Thermoplastic

Plug/Socket:

Plug

Connector Size:

Standard

Checking for live stock

The Deutsch HDP26‑24‑47PE‑L015 from the HDP20 series is a heavy‑duty circular plug designed for panel or bulkhead mounting, offering 47 positions (male contacts) in a thermoplastic composite shell. Engineered for harsh‑environment applications, it features sealed construction with an IP67 rating, making it suitable for outdoor, industrial and off‑highway use where durability and environmental resistance are essential.

Core Features and Benefits of Buying the Deutsch Bulkhead Mount Connector Plug

47‑pole plug housing designed for male terminals and wire‑to‑panel mounting.
Thermoplastic shell (PA66 GF) with quick‑connect bayonet coupling for efficient assembly.
Sealed to IP67 for dust‑tight and waterproof performance, rated to –55 °C to +125 °C.
Supports contact sizes 16 and 20, with current ratings up to 13 A (size 16) and 7.5 A (size 20) in some configurations.
Bulkhead /(panel‑mount) format with shell size 24 and black body finish.
Suitable for demanding applications with a minimum of 100 mating cycles, vibration-rated to 20 g (10‑2000 Hz).

Designed for Rugged Electrical Systems

This connector is engineered to withstand the mechanical, thermal, and environmental stresses encountered in heavy‑equipment, transport, and industrial automation systems. The composite shell resists chemical, oil and fluid exposure, while the sealed design provides reliable ingress protection in harsh environments. Rear‑insert crimp contacts and precision alignment features ensure secure terminations and accurate panel integration.

Application Potential of the Product

Cable‑to‑panel wiring in off‑highway vehicles, agriculture and mining equipment.
Industrial machines and control enclosures.
Marine, rail or transport systems.
Bulkhead mounting in junction boxes, instrumentation and power distribution panels.
Harsh‑environment electronic systems.
