SMT Quartz 8GHz Latching 12Vdc
Product Information
Dimensions:
15 x 12.7 x 12mm
Coil Voltage:
12V dc
Coil Resistance:
205Ω
Life:
3000000 (Cold Switch) cycles, 500 (Hot Switch) cycles
VSWR Voltage Standing Wave Ratio:
1.4 @ 8 GHz
Coil Power:
5W
Impedance:
50Ω
Maximum Operating Temperature:
+85°C
Relay Type:
HF Relay
Operating Temperature Range:
-40 → +85°C
Isolation:
40 dB @ 8 GHz
Latching:
Yes
Contact Configuration:
SPDT
Depth:
12mm
Relay Switching Classification:
General Purpose Relay
Special Features:
High Frequency, High Life Span, High Power Applications, High Repeatability
Insertion Loss:
0.5 dB @ 8 GHz
Mounting Type:
PCB Mount
Maximum Coil Frequency:
8GHz
Operating Time Including Bounce:
5ms
Length:
15mm
Height:
12mm
Minimum Operating Temperature:
-40°C
Number of Poles:
1
Contact Material:
Copper
Checking for live stock
FAQs
Yes. You can also search R516332100 on website for other similar products.
We accept all major payment methods for all products including ET16943002. Please check your shopping cart at the time of order.
You can order Radiall brand products with R516332100 directly through our website or call us at +44 (0) 3303 800 157 or email our support team at sales@enrgtech.co.uk.
Yes. Our products in HF & RF Relays category are shipped in lowest possible time.
You will get a confirmation email regarding your order of SMT Quartz 8GHz Latching 12Vdc. You can also check on our website or by contacting our customer support team for further order details on SMT Quartz 8GHz Latching 12Vdc.
We use our internationally recognized delivery partners UPS/DHL. Collection of ET16943002 can also be arranged for the customer by international shipments through contacting our customer support team. Additionally, you can also search "Radiall" products on our website by using Enrgtech's Unique Manufacturing Part Number ET16943002.
Yes. We ship R516332100 Internationally to many countries around the world.
This is SMT Quartz 8GHz Latching 12Vdc manufactured by Radiall. The manufacturer part number is R516332100. The given dimensions of the product include 15 x 12.7 x 12mm. The coil voltage of the product is 12v dc. It holds up to 205ω coil resistance. It is capable of doing 3000000 (cold switch) cycles, 500 (hot switch) cycles in a lifetime . Additionally, it has 1.4 @ 8 ghz VSWR voltage standing wave ratio . Robust coil power of 5w. It has an impedance value of 50ω. It has a maximum operating temperature of +85°c. This is basically a hf relay. The product has -40 → +85°c of operating temperature range. Features a 40 db @ 8 ghz isolation. Latching Options - yes. The contact is equipped with spdt configuration. The product comes in 12mm depth. It has a general purpose relay switching relay configuration . The product also provides special features, such as high frequency, high life span, high power applications, high repeatability. Allows 0.5 db @ 8 ghz of insertion loss. The product is available in pcb mount configuration. With about 8ghz maximum coil frequency . Moreover, the product offers a 5ms operating time including bounce . Its accurate length is 15mm. In addition, the height is 12mm. Whereas, the minimum operating temperature of the product is -40°c. It has equipped with 1 poles. The product is made from sturdy copper materials.
