Housing Material:
Polyamide
Number of Contacts:
4
Colour:
Black
Length:
33mm
Contact Gender:
Female
Current:
5A
Width:
12.22 mm
Depth:
7.85mm
Number of Rows:
2
Standards/Approvals:
ISO 6988:1985-02, IEC 60512-13-5:2006-02, EU REACH, EN 60695-10-2, EN 60695-2-12, IEC 60068-2-70:1995-12, CAT5 (IEC 11801), UL 94 V0, IEC 60512-5-1:2002-02, IEC 60512-3-1:2002-02, EN 60695-2-13, IEC 60512-1-1:2002-02, cULus Recognised E60425-19920306, IEC 60068-2-6:2007-12, EU RoHS, IEC 60512-9-1:2010-03, IEC 60512-13-2:2006-02, EN 50173, IEC 60512-1-2:2002-02, VDE report with production monitoring 40042389, ISO/IEC 11801, IEC 60664-1:2007-04, CHINA RoHS
Voltage:
160 V
Termination Type:
Crimp
Pitch:
2.54mm
Product Type:
PCB Terminal Block
Mount Type:
Push-in
HTSUS:
8536.90.4000
RoHS Status:
ROHS3 Compliant
Termination Style:
Crimp
Housing Material:
Polyamide (PA), Nylon
Operating Temperature:
-
Screw Size:
-
Wire Strip Length:
4.1-4.5mm
Type:
Plug Housing for Female Sockets
Number of Positions:
8
Contact Tail Length:
-
Wire Gauge or Range - mm²:
0.14-0.75mm²
Plug Wire Entry:
180°
Insulation Height:
0.309" (7.85mm)
REACH Status:
REACH Unaffected
Material Flammability Rating:
UL94 V-0
Package:
Box
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Current - IEC:
6A
Wire Gauge or Range - AWG:
18-26 AWG
Voltage - UL:
150 V
Torque - Screw:
-
standardLeadTime:
9 Weeks
Contact Mating Finish:
Gold
Voltage - IEC:
160 V
Ingress Protection:
IP20
Features:
Solder Retention
Mounting Type:
Free Hanging (In-Line)
Color:
Black
Series:
COMBICON DMCC
Positions Per Level:
4
Header Orientation:
-
Current - UL:
6 A
Pitch:
0.100" (2.54mm)
Number of Levels:
2
Contact Material:
Copper Alloy
ECCN:
EAR99
