HTSUS:
8536.69.4040
RoHS Status:
RoHS Compliant
Termination Style:
Solder
Operating Temperature:
-
Type:
Header, Male Pins, Shrouded (4 Side)
Number of Positions:
4
Wire Gauge or Range - mm²:
-
title:
1845027
Plug Wire Entry:
-
Manufacturer:
Phoenix Contact
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Current - IEC:
6A
Number of Levels:
2
Wire Gauge or Range - AWG:
-
Voltage - UL:
150 V
standardLeadTime:
9 Weeks
Contact Mating Finish:
Gold
Voltage - IEC:
160 V
Features:
Solder Retention
Mounting Type:
Surface Mount
Color:
Black
Series:
COMBICON DMC
Positions Per Level:
2
Packaging:
Tape & Reel (TR)
Header Orientation:
90°, Right Angle
Current - UL:
6 A
Pitch:
0.100" (2.54mm)
ECCN:
EAR99
Connector System:
COMBICON DFMC 0.5
Number of Contacts:
4
Termination Type:
Solder
Housing Material:
Liquid Crystal Polymer
Shrouded/Unshrouded:
Shrouded
Series:
DMC
Contact Material:
Copper Alloy
Contact Gender:
Male
Row Pitch:
2.54mm
Current:
6A
Number of Rows:
2
Standards/Approvals:
cULus, DIN 50018, IEC 60068-2-70, IEC 60512-1-1, IEC 60512-1-2, IEC 60512-13-5, IEC 60512-15-1, IEC 60512-3-1, IEC 60512-5-1, IEC 60664-1, UL 94 V0, VDE report
Voltage:
160 V
Contact Plating:
Gold Plated
Pitch:
2.54mm
Product Type:
PCB Header
Maximum Operating Temperature:
105°C
Minimum Operating Temperature:
-40°C
Mount Type:
Surface
