Shrouded/Unshrouded:
Shrouded
Row Pitch:
5mm
Housing Material:
Polyamide
Tail Pin Length:
3.23mm
Connector System:
COMBICON MSTB 2.5
Number of Rows:
1
Contact Plating:
Tin
Product Type:
PCB Header
Maximum Operating Temperature:
100°C
Minimum Operating Temperature:
-40°C
Contact Gender:
Male
Standards/Approvals:
CSA 13631-2585951, cULus E60425-19931011, EN 60695-10-2, EN 60695-2-12, EN 60695-2-13, IEC 60068-2-70, IEC 60112, IEC 60512-1-1, IEC 60512-1-2, IEC 60512-13-5, IEC 60512-15-1, IEC 61984, REACH, RoHS, UL 94 V0, VDE 40050648
Mount Type:
Solder
Current:
12A
Orientation:
Straight
Series:
MSTB 2/5-G
Voltage:
32 V
Termination Type:
Solder
Pitch:
5mm
Mating Pin Length:
3.23mm
Number of Contacts:
2
Contact Material:
Copper Alloy
HTSUS:
8536.69.4040
RoHS Status:
ROHS3 Compliant
Termination Style:
Solder
Housing Material:
Polyamide (PA), Nylon
Operating Temperature:
-
Screw Size:
-
Wire Strip Length:
-
Type:
Header, Male Pins, Shrouded (2 Side)
Number of Positions:
2
Wire Gauge or Range - mm²:
-
Plug Wire Entry:
-
Insulation Height:
0.339" (8.61mm)
REACH Status:
REACH Unaffected
edacadModel:
1754436 Models
Material Flammability Rating:
UL94 V-0
edacadModelUrl:
/en/models/260452
Package:
Bulk
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Current - IEC:
12A
Contact Tail Length:
0.138" (3.50mm)
Voltage - UL:
300 V
Torque - Screw:
-
standardLeadTime:
6 Weeks
Contact Mating Finish:
Tin
Voltage - IEC:
400 V
Ingress Protection:
-
Features:
-
Mounting Type:
Through Hole
Color:
Green
Series:
COMBICON MSTB
Positions Per Level:
2
Header Orientation:
90°, Right Angle
Current - UL:
15 A
Wire Gauge or Range - AWG:
-
Pitch:
0.197" (5.00mm)
Number of Levels:
1
Contact Material:
-
ECCN:
EAR99
