Contact Finish - Mating:
Gold
Style:
Board to Cable/Wire
HTSUS:
8536.69.4040
RoHS Status:
ROHS3 Compliant
Operating Temperature:
-
Contact Finish Thickness - Post:
100.0µin (2.54µm)
Number of Positions:
2
Contact Finish - Post:
Tin
edacadModel:
1720641002 Models
Overall Contact Length:
-
Insulation Height:
0.572" (14.53mm)
Insulation Color:
Black
REACH Status:
REACH Unaffected
Shrouding:
Shrouded - 4 Wall
Applications:
Automotive, General Purpose, Industrial, Telecommunications
Number of Rows:
2
Material Flammability Rating:
UL94 V-0
edacadModelUrl:
/en/models/4839913
Contact Shape:
Square
Mated Stacking Heights:
-
Voltage Rating:
-
Row Spacing - Mating:
0.224" (5.70mm)
Connector Type:
Header
Contact Length - Mating:
-
Number of Positions Loaded:
All
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Contact Finish Thickness - Mating:
30.0µin (0.76µm)
Fastening Type:
Locking Ramp
Termination:
Solder
standardLeadTime:
14 Weeks
Current Rating (Amps):
-
Contact Length - Post:
0.142" (3.60mm)
Pitch - Mating:
-
Ingress Protection:
-
Features:
Board Guide, Glow Wire Compliant
Mounting Type:
Through Hole, Right Angle
Series:
Mega-Fit
Packaging:
Tray
Insulation Material:
Liquid Crystal Polymer (LCP)
Contact Type:
Male Pin
Contact Material:
Copper
Base Product Number:
172064
ECCN:
EAR99
Connector System:
Wire-to-Board
Number of Contacts:
2
Orientation:
Right Angle
Housing Material:
Thermoplastic
Shrouded/Unshrouded:
Shrouded
Series:
172043
Contact Material:
Copper
Contact Gender:
Male
Row Pitch:
5.7mm
Current:
23.5A
Number of Rows:
2
Pitch:
5.7mm
Termination Type:
Through Hole
Contact Plating:
Gold
Product Type:
PCB Header
Maximum Operating Temperature:
120°C
Minimum Operating Temperature:
-40°C
Mount Type:
Through Hole
