Maximum Frequency Range Square Pulse and Arbitrary Waveform:
20MHz
Dimensions:
213 x 210 x 88mm
FM Modulation:
Yes
Width:
210mm
Variable Sweep:
Yes
Maximum Frequency Range Sinewave:
20MHz
Minimum Frequency Range Sinewave:
0.01Hz
Model Number p:
BK4040B
Maximum Frequency Range Triangle/Saw:
2MHz
Internal and External Amplitude Modulation:
Yes
Maximum Operating Temperature:
+50°C
Minimum Frequency Range Triangle/Saw:
0.01Hz
Output Amplitude:
10 mVpp → 10 Vpp (into 50 Ω), 20 mVpp → 20 Vpp (Open Circuit)
Minimum Operating Temperature:
0°C
Length:
213mm
Interface Type:
USB
Minimum Frequency Range Square Pulse and Arbitrary Waveform:
0.01 Hz
Input Impedance:
1 (Trigger) kΩ, 10 (Modulation) kΩ
Digital Frequency:
Yes
Weight:
2.5kg
Frequency Range Square Pulse and Arbitrary Waveform:
0.01 Hz → 20 MHz
Height:
88mm
Internal Linear and Log Sweep:
Yes
Output Impedance:
50Ω
Digital Amplitude and Offset:
Yes
