Connector System:
Wire-to-Board
Number of Contacts:
40
Minimum Operating Temperature:
65°C
Housing Material:
Beryllium Copper Alloy, Cover Insulation: Glass Filled Polybutylene Terephthalate, Glass Filled Polybutylene Terephthalate, Header Insulation: Glass Filled Liquid Crystal Polymer, Strain Relief: Stainless Steel
Shrouded/Unshrouded:
Shrouded
Series:
451
Contact Material:
Beryllium Copper Alloy
Row Pitch:
1.27mm
Current:
0.75A
Number of Rows:
2
Standards/Approvals:
ASTM B488-01, ASTM B689-97, EIA-364, IEC-60512-6d-2e-6c, J-STD-020E, SAE AMS-QQ-N-290, UL File No. E68080
Voltage:
125 V
Contact Plating:
Nickel
Pitch:
1.27mm
Product Type:
PCB Header
Maximum Operating Temperature:
130°C
Mount Type:
Wire
Wire Type:
Ribbon Cable
HTSUS:
8536.69.4051
RoHS Status:
ROHS3 Compliant
Contact Finish Thickness:
30.0µin (0.76µm)
Number of Positions:
40
REACH Status:
REACH Unaffected
Cable Termination:
IDC
Number of Rows:
2
Package:
Box
Wire Gauge:
30 AWG
Connector Type:
Receptacle
Contact Finish:
Gold
Moisture Sensitivity Level (MSL):
Not Applicable
Fastening Type:
-
standardLeadTime:
21 Weeks
Features:
Feed Through, Polarizing Key
Mounting Type:
Free Hanging (In-Line)
Color:
-
Series:
451
Pitch:
0.050" (1.27mm)
Contact Type:
Female Socket
Row Spacing:
0.050" (1.27mm)
Base Product Number:
45140
ECCN:
EAR99
