Cinch PCBEdge Connector, PCB Mount Mount, 49 Way, 2 Row, 2.54mm Pitch, 3A

Enrgtech Part No: ET24599773
|
Manufacturer Part No:
BA000010000CE00
|
Manufacturer: Cinch

BA000010000CE00 Cinch PCBEdge Connector, PCB Mount Mount, 49 Way, 2 Row, 2.54mm Pitch, 3A

Product Information

Current Rating:

Minimum Operating Temperature:

-55°C

Mounting Type:

PCB Mount

Maximum Operating Temperature:

+105°C

Body Orientation:

Straight

Termination Method:

Solder

Length:

138.7mm

Housing Material:

Glass Fibre Reinforced PET

Width:

9.3mm

Depth:

15.1mm

Number of Rows:

Contact Plating:

Gold over Nickel

Checking for live stock

Upgrade your printed circuit board connectivity with the Cinch BA000010000CE00, a robust edge connector engineered for reliability in demanding electronic assemblies. Designed with 49 gold-plated brass contacts, this PCB-mount, solder-terminated connector ensures durable performance and excellent signal integrity. It combines robust design, precise engineering, and consistent performance, making it a top-tier choice for UK and global technical buyers.

Key Features and Benefits

Pitch: 2.54 mm (0.1 in).
Rows: 2.
Current Rating: 3 A per contact.
Operating Temp Range: –55 °C to +105 °C.
Housing Material: Glass‑fibre reinforced PET for optimal mechanical strength.
Plating: Gold over nickel for superior corrosion resistance.
Keying Way: Built‑in for error‑free mating.
Dimensions: Length 138.7 mm × Width 9.3 mm × Depth 15.1 mm.

Why Engineers Rely on this Product?

This connector’s precise 2.54 mm pitch and 49-contact layout are ideal for compact, high-density PCB designs in industrial, computing, and communications equipment. Its sturdy, glass-reinforced PET body and gold-over-nickel contacts deliver long-term durability and high reliability in harsh environments. With a useful keying feature, it helps prevent mis-mating and installation errors, vital for technical and B2B applications.

AT/XT PC Edge Connectors Data Sheet(Technical Reference)
