Newhaven Display Intl NHD-0216B3Z-FL-GBW-V3

NHD-0216B3Z-FL-GBW-V3 Newhaven Display Intl
Newhaven Display Intl

Product Information

Character Size:
5.23mm H x 3.00mm W
HTSUS:
8531.20.0020
RoHS Status:
ROHS3 Compliant
Character Format:
5 x 8 Dots
Display Format:
16 x 2
Operating Temperature:
-20°C ~ 70°C
Controller Type:
PIC16F691
REACH Status:
REACH Unaffected
Interface:
I²C, RS-232, SPI
Package:
Box
Viewing Area:
64.50mm L x 16.40mm W
Moisture Sensitivity Level (MSL):
Not Applicable
Text Color:
Black
standardLeadTime:
16 Weeks
Background Color:
Green
Display Type:
STN - Super-Twisted Nematic
Series:
-
Number of Characters:
32
Outline L x W x H:
84.00mm x 44.00mm x 13.50mm
Voltage - Supply:
4.7V ~ 5.5V
Base Product Number:
NHD-0216
Display Mode:
Transflective
Dot Size:
0.56mm W x 0.61mm H
Backlight:
LED - Yellow/Green
ECCN:
EAR99
Checking for live stock

The Newhaven Display Intl NHD-0216B3Z-FL-GBW-V3 is a sophisticated Character Display Module designed for versatility and efficiency in various applications. This display module is particularly noted for its transflective properties, which combine reflective and transmissive methods to provide excellent visibility in both bright and low-light conditions. The display utilises a 5 x 8 dot matrix on an STN (Super-Twisted Nematic) panel, which is renowned for its reliability and sharp contrast.

  • Physical Dimensions

84.00mm x 44.00mm x 13.50mm is a compact form factor that can fit into various devices without taking up much space.

Core Features and Benefits of the Character Display Module

  • STN - Super-Twisted Nematic offers a good balance between performance and cost.
  • 5 x 8 dots, suitable for displaying text and basic graphics.
  • LED in Yellow/Green, providing clear visibility in various lighting conditions.
  • I²C, RS-232, and SPI allow for flexible integration with different systems and microcontrollers.

Applications of the NHD-0216B3Z-FL-GBW-V3

This display module from Newhaven Display Intl is a testament to the advancements in display technology, offering a blend of performance, versatility, and reliability for a wide range of applications, including:

  • Industrial Control Systems: Its robustness and clear display make it ideal for industrial environments.
  • Consumer Electronics: Suitable for devices requiring a simple yet effective display interface.
  • Automotive Applications: Its transflective nature is perfect for vehicle dashboard displays, which must be readable in bright sunlight and at night.
  • Telecommunication Devices: Can be used in devices like modems and routers for status displays.
  • Medical Equipment: Its reliability and clarity make it suitable for various medical devices that require a simple display.
