Number of Levels:
1
Fused:
No
Termination Type:
Push-in
Colour:
Yellow, Black
Minimum Operating Temperature:
-60°C
Minimum Wire Size AWG:
26 AWG
Terminal Block Current:
24A
Number of Positions:
1
Hazardous Area Certification:
IECEx/ATEX
Standards/Approvals:
RS, UL Recognised, VDE, ABS, EAC, IECEX, DNV GL, LR, NK, EAC Ex, IEC 60947-7-1, Bureau Veritas, ATEX, IECEE CB Scheme, cULus Recognised, cUL Recognised, CSA
Voltage:
800 V
Cable CSA:
0.14 to 4 mm²
Maximum Wire Size AWG:
12 AWG
Product Type:
Feed Through Terminal Block
Maximum Operating Temperature:
105°C
Sub Type:
Feed Through
HTSUS:
8536.90.4000
RoHS Status:
ROHS3 Compliant
Termination Style:
Push In
Material - Insulation:
Polyamide (PA), Nylon
Type:
Feed Through
Number of Positions:
2
Wire Gauge or Range - mm²:
0.14-4mm²
REACH Status:
REACH Unaffected
Material Flammability Rating:
UL94 V-0
Package:
Bulk
Stripping Length:
8mm ~ 10mm
Current - IEC:
24 A
Wire Gauge or Range - AWG:
12-26 AWG
Voltage - UL:
600V
standardLeadTime:
5 Weeks
Terminal - Width:
5.2mm
Disconnect Type:
-
Voltage - IEC:
800V
Features:
-
Color:
Black, Yellow
Series:
CLIPLINE PT
Fuse Type:
-
Current - UL:
20 A
Number of Levels:
1
ECCN:
EAR99
