Number of Levels:
1
Fused:
No
Termination Type:
Screw
Series:
UT 2.5-QUATTRO
Colour:
Grey
Minimum Operating Temperature:
60°C
Minimum Wire Size AWG:
26 AWG
Terminal Block Current:
30A
Hazardous Area Certification:
KEMA, IECEx KEM 06.0013 U
Standards/Approvals:
ATEX, 17.00013.272, 13403/D0 BV, 09 ME 140, VDE, NEPSI, LR2014888TA, DNV, CSA, CCC, cULus Recognised, IECEX, IECEE CB Scheme, IEC 60947-7-1, EAC Ex
Voltage:
500 V
Cable CSA:
0.14 to 4 mm²
Maximum Wire Size AWG:
12 AWG
Product Type:
DIN Rail Terminal Block
Maximum Operating Temperature:
130°C
Sub Type:
Feed Through
HTSUS:
8536.90.4000
RoHS Status:
ROHS3 Compliant
Termination Style:
Screw
Material - Insulation:
Polyamide (PA), Nylon
Type:
Feed Through
Number of Positions:
4
Wire Gauge or Range - mm²:
0.14-4mm²
REACH Status:
REACH Affected
Material Flammability Rating:
UL94 V-0
Manufacturer:
Phoenix Contact
Stripping Length:
9mm
Moisture Sensitivity Level (MSL):
Not Applicable
Current - IEC:
24 A
Number of Levels:
1
Wire Gauge or Range - AWG:
12-26 AWG
Voltage - UL:
150V
standardLeadTime:
8 Weeks
Terminal - Width:
5.2mm
Disconnect Type:
-
Voltage - IEC:
500V
Features:
-
Color:
Gray
Series:
CLIPLINE UT
Packaging:
Bulk
Fuse Type:
-
Current - UL:
20 A
ECCN:
EAR99
