Number of Levels:
1
Fused:
No
Minimum Operating Temperature:
-60°C
Series:
PTPOWER 95 P
Colour:
Grey
Minimum Wire Size AWG:
4 AWG
Terminal Block Current:
232A
Number of Positions:
1
Hazardous Area Certification:
No
Standards/Approvals:
EAC Ex, IEC 60947-7-1, IECEX, UL, cUL, DNV GL, EAC, Bureau Veritas, CSA, cULus, ATEX
Voltage:
1500 V
Cable CSA:
25 to 95 mm²
Maximum Wire Size AWG:
4 AWG
Product Type:
High Current Connector
Maximum Operating Temperature:
105°C
Sub Type:
High Current
HTSUS:
8536.69.8000
RoHS Status:
RoHS Compliant
Termination Style:
Push In, Spring
Material - Insulation:
Polyamide (PA), Nylon
Type:
Feed Through
Number of Positions:
2
Wire Gauge or Range - mm²:
25-95mm²
Material Flammability Rating:
UL94 V-0
Package:
Bulk
Stripping Length:
40mm
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Current - IEC:
232 A
Wire Gauge or Range - AWG:
4/0-4 AWG
Voltage - UL:
1000V
standardLeadTime:
5 Weeks
Terminal - Width:
25.0mm
Disconnect Type:
-
Voltage - IEC:
1500V
Features:
-
Color:
Gray
Series:
CLIPLINE PTPOWER
Fuse Type:
-
Current - UL:
230 A
Number of Levels:
1
ECCN:
EAR99
