Maximum Temperature:
+70°C
AC or DC Output Voltage:
dc
Minimum Temperature:
-20°C
AC or DC Input Voltage:
ac, dc
Width:
27mm
MTBF:
700000h
Electrical Phase:
1
Type:
Switched Mode
Load Regulation:
1%
Standards Met:
CE
Efficiency:
88%
Input Voltage:
100→240 V ac / 140→340V dc
Output Voltage Adjustment Range:
21.6 → 26.4V
Ripple And Noise:
120mV
Depth:
102mm
Special Features:
Overvoltage and Short Circuit Protection
Better World Verification:
Green Premium
Better World Product:
Yes
Mounting Type:
DIN Rail Mount
Output Current:
3.13A
Series:
ABLS1A
Height:
123.6mm
Output Voltage:
24V dc
Power Rating:
75W
HTSUS:
8504.40.9520
RoHS Status:
ROHS3 Compliant
Power (Watts):
75W
Current - Output (Max):
3.13A
Approval Agency:
CB, CE, CSA, CuL, EAC, EN, IEC, KC, NEC Class 2, UL
Input Type:
AC or DC
Applications:
ITE (Commercial), Laboratory
Voltage - Output 4:
-
Voltage - Output 5:
-
Voltage - Output 6:
-
Voltage - Output 1:
24V
Voltage - Output 2:
-
Voltage - Output 3:
-
Efficiency:
88%
Manufacturer:
Schneider Electric
DC Voltage - Input (Max):
340V
DC Voltage - Input (Min):
140V
Minimum Load Required:
-
Size / Dimension:
4.02" L x 1.06" W x 4.87" H (102.0mm x 27.0mm x 123.6mm)
standardLeadTime:
9 Weeks
Voltage - Isolation:
3 kV
AC Voltage - Input:
100 ~ 240 VAC
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Features:
IP20, Universal Input
Series:
-
Operating Temperature:
-20°C ~ 70°C (With Derating)
Packaging:
Box
Standard Number:
60950-1; 61010-1; 62368-1
Number of Outputs:
1
ECCN:
EAR99
