Maximum Temperature:
+70°C
AC or DC Output Voltage:
dc
Minimum Temperature:
-25°C
AC or DC Input Voltage:
ac, dc
Width:
60mm
MTBF:
>500000h
Electrical Phase:
1
Type:
AC-DC Switching Power Supply
Standards Met:
61000-4-4, 61000-4-5, 61000-4-6, CE Certified, cULus Listed, EAC, EN 50178/VDE 0160, EN 55022, EN 60204, EN 60950, EN 61000-3-2, EN 61000-4-11, EN 61000-4-2, EN 61000-4-3, EN 61000-4-8, IEC 1709, IEC 60068-2-27, IEC 60068-2-6, IEC 61558-2-16, VDE 0100-410/DIN57100-410, VDE 0106-101
Efficiency:
92%
Input Voltage:
85 → 264V ac
Number of Outputs:
1
Output Voltage Adjustment Range:
42 → 56V
Ripple And Noise:
<100mV
Depth:
100mm
Special Features:
Compact Size, Easy to Maintain, Flexible, High Efficiency
Mounting Type:
DIN Rail Mount
Output Current:
5A
Series:
PRO ECO
Height:
125mm
Output Voltage:
48V dc
Power Rating:
240W
Manufacturer Standard Lead Time:
16 Weeks
Number of Outputs:
1
Detailed Description:
Enclosed AC DC Converter 1 Output 48V 5A 85 ~ 264 VAC, 80 ~ 370 VDC Input
Voltage - Isolation:
3kV
Features:
Adjustable Output, IP20, Universal Input
Mounting Type:
DIN Rail
Applications:
ITE (Commercial)
Series:
PRO ECO (240W)
Voltage - Output 1:
48V
Size / Dimension:
3.94" L x 2.36" W x 4.92" H (100.0mm x 60.0mm x 125.0mm)
Efficiency:
92%
Power (Watts):
240W
Current - Output (Max):
5A
Approvals:
CE, cULus, EAC
Voltage - Input:
85 ~ 264 VAC, 80 ~ 370 VDC
Operating Temperature:
-25°C ~ 70°C
Type:
Enclosed
Manufacturer:
Weidmuller
