Number of Levels:
2
Fused:
No
Termination Type:
Spring Clamp
Series:
STTB 2.5
Colour:
Grey
Minimum Operating Temperature:
-50°C
Minimum Wire Size AWG:
28 AWG
Terminal Block Current:
22A
Hazardous Area Certification:
IECEx/ATEX
Standards/Approvals:
ATEX, Bureau Veritas, CSA, UL Recognised, VDE, KR, LR, NK, cUL Recognised, cULus Recognised, DNV GL, EAC, EAC Ex, IEC 60947-7-1, IECEE CB Scheme, IECEX
Voltage:
500 V
Cable CSA:
0.08 to 4 mm²
Maximum Wire Size AWG:
12 AWG
Product Type:
Double Level Terminal Block
Maximum Operating Temperature:
110°C
Sub Type:
Multi-Level
HTSUS:
8536.69.8000
RoHS Status:
ROHS3 Compliant
Termination Style:
Push In, Spring
Material - Insulation:
Polyamide (PA), Nylon
Type:
Feed Through
Number of Positions:
4
Wire Gauge or Range - mm²:
0.08-4mm²
REACH Status:
REACH Unaffected
Material Flammability Rating:
UL94 V-0
Manufacturer:
Phoenix Contact
Stripping Length:
10mm
Moisture Sensitivity Level (MSL):
Not Applicable
Current - IEC:
22 A
Number of Levels:
2
Wire Gauge or Range - AWG:
12-28 AWG
Voltage - UL:
600V
standardLeadTime:
8 Weeks
Terminal - Width:
5.2mm
Disconnect Type:
-
Voltage - IEC:
500V
Features:
-
Color:
Gray
Series:
CLIPLINE STTB
Packaging:
Bulk
Fuse Type:
-
Current - UL:
20 A
ECCN:
EAR99
