Number of Levels:
1
Fused:
No
Termination Type:
Spring Clamp
Series:
ST 2.5-QUATTRO GN
Colour:
Green
Minimum Wire Size AWG:
28 AWG
Terminal Block Current:
28A
Hazardous Area Certification:
IECEx, KEMA
Standards/Approvals:
VDE, 09 ME 140, 13403/D0 BV, 17.00013.272, ATEX, CCC, CSA, cULus Recognised, DNV, EAC Ex, IEC 60947-7-1, IECEE CB Scheme, IECEX, LR2014888TA, NEPSI
Voltage:
800 V
Cable CSA:
0.08 to 4 mm²
Maximum Wire Size AWG:
12 AWG
Product Type:
DIN Rail Terminal Block
Sub Type:
Feed Through
HTSUS:
8536.69.8000
RoHS Status:
ROHS3 Compliant
Termination Style:
Push In, Spring
Material - Insulation:
Polyamide (PA), Nylon
Type:
Feed Through
Number of Positions:
4
Wire Gauge or Range - mm²:
0.08-4mm²
REACH Status:
REACH Unaffected
Material Flammability Rating:
UL94 V-0
Manufacturer:
Phoenix Contact
Stripping Length:
10mm
Moisture Sensitivity Level (MSL):
Not Applicable
Current - IEC:
24 A
Number of Levels:
1
Wire Gauge or Range - AWG:
12-28 AWG
Voltage - UL:
600V
standardLeadTime:
8 Weeks
Terminal - Width:
5.2mm
Disconnect Type:
-
Voltage - IEC:
800V
Features:
-
Color:
Green
Series:
CLIPLINE ST
Packaging:
Bulk
Fuse Type:
-
Current - UL:
20 A
ECCN:
EAR99
