Number of Levels:
2
Fused:
Yes
Termination Type:
Screw
Series:
UTTB 4-PE
Colour:
Green, Yellow
Minimum Operating Temperature:
-60°C
Minimum Wire Size AWG:
26 AWG
Hazardous Area Certification:
IECEx KEM 06.0013 U, KEMA 06 ATEX 0017 U
Standards/Approvals:
DNV, ATEX, CCC, CSA, cUL, cULus, EAC, EAC Ex, GL, GOST, IECEX, NEPSI, PRS, RS, UL
Cable CSA:
0.14 to 6 mm²
Maximum Wire Size AWG:
10 AWG
Product Type:
Fused DIN Rail Terminal
Maximum Operating Temperature:
110°C
Sub Type:
Feed Through
HTSUS:
8536.90.4000
RoHS Status:
ROHS3 Compliant
Termination Style:
Screw
Material - Insulation:
Polyamide (PA), Nylon
Type:
Ground, Earth
Number of Positions:
4
Wire Gauge or Range - mm²:
0.14-6mm²
title:
3044759
REACH Status:
REACH Affected
Material Flammability Rating:
UL94 V-0
Manufacturer:
Phoenix Contact
Stripping Length:
9mm
Moisture Sensitivity Level (MSL):
Not Applicable
Number of Levels:
2; Connected
Wire Gauge or Range - AWG:
10-26 AWG
Voltage - UL:
-
standardLeadTime:
8 Weeks
Terminal - Width:
6.2mm
Disconnect Type:
-
Voltage - IEC:
-
Features:
-
Color:
Green, Yellow
Series:
CLIPLINE UTTB
Packaging:
Bulk
Fuse Type:
-
ECCN:
EAR99
