Number of Levels:
1
Fused:
No
Termination Type:
Screw
Series:
UT 4-PE
Colour:
Yellow, Green
Minimum Wire Size AWG:
26 AWG
Hazardous Area Certification:
ATEX
Standards/Approvals:
ATEX, CCC, CSA, cULus, DNV, EAC, EAC Ex, IEC 60947-7-2, IECEE CB, IECEX, NEPSI, PRS, RS, VDE
Voltage:
690 V
Pitch:
6.2mm
Cable CSA:
0.14 to 6 mm²
Maximum Wire Size AWG:
10 AWG
Product Type:
Earth Terminal Block
Maximum Operating Temperature:
110°C
Minimum Operating Temperature:
-60°C
HTSUS:
8536.69.8000
RoHS Status:
ROHS3 Compliant
Termination Style:
Screw
Material - Insulation:
Polyamide (PA), Nylon
Type:
Ground, Earth
Number of Positions:
2
Wire Gauge or Range - mm²:
0.14-6mm²
REACH Status:
REACH Affected
Material Flammability Rating:
UL94 V-0
Package:
Box
Stripping Length:
9mm
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Wire Gauge or Range - AWG:
10-26 AWG
Voltage - UL:
-
standardLeadTime:
8 Weeks
Terminal - Width:
6.2mm
Disconnect Type:
-
Voltage - IEC:
-
Features:
-
Color:
Green, Yellow
Series:
CLIPLINE UT
Fuse Type:
-
Number of Levels:
1
ECCN:
EAR99
