Number of Levels:
1
Fused:
No
Termination Type:
Screw
Series:
UT 6
Colour:
White
Minimum Operating Temperature:
-60°C
Minimum Wire Size AWG:
24 AWG
Terminal Block Current:
41A
Hazardous Area Certification:
IECEx/ATEX
Standards/Approvals:
IEC 60947-7-1, VDE, UL, RS, PRS, IECEE CB, EAC, DNV GL, cULus, cUL, CSA
Voltage:
1 kV
Cable CSA:
0.2 to 10 mm²
Maximum Wire Size AWG:
8 AWG
Product Type:
Feed Through Terminal Block
Maximum Operating Temperature:
105°C
Sub Type:
Feed Through
HTSUS:
8536.90.4000
RoHS Status:
ROHS3 Compliant
Termination Style:
Screw
Material - Insulation:
Polyamide (PA), Nylon
Type:
Feed Through
Number of Positions:
2
Wire Gauge or Range - mm²:
0.2-10mm²
REACH Status:
REACH Affected
Material Flammability Rating:
UL94 V-0
Package:
Bulk
Stripping Length:
10mm
Moisture Sensitivity Level (MSL):
Not Applicable
Current - IEC:
41 A
Wire Gauge or Range - AWG:
8-24 AWG
Voltage - UL:
600V
standardLeadTime:
8 Weeks
Terminal - Width:
8.2mm
Disconnect Type:
-
Voltage - IEC:
1000V
Features:
-
Color:
White
Series:
CLIPLINE UT
Fuse Type:
-
Current - UL:
50 A
Number of Levels:
1
ECCN:
EAR99
